23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD) 23.3.Device table(DGSD) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 1 DGSD0011 1 TABLE ﾃｰﾌﾞﾙ 3 DGSD0101 1 GUIDE ｶﾞｲﾄﾞ 4 DGSD0111 1 GUIDE ｶﾞｲﾄﾞ 5 DGSD060…
Ref.32-5
Ref.32-5
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
M
N
N
N
L
L
M
x8.5
87
104
109
111
106
97
81
81
112
107
132
93
114
121
122
90
114
90
114
122
114
90
114
90
122
122
94
115
96
119
91
105
99
115
94
115
91
133
133
134
94
115
119
96
86
104
109
83
117
86
104
109
104
86
104
86
86
104
109
81
109
104
86
109
104
86
110
105
90
118
88
59
59
72
72
55
55
59
59
75
75
54
54
75
75
63
63
63
63
75
75
54
54
75
75
72
72
55
55
22
62
69
69
67
67
60
23
47
20
19
31
20
19
13
15
14
39
68
33
38
36
25
26
69
76
29
28
66
65
D
B
A
C
E
F
G
102
107
115
95
115
98
115
95
115
98
113
85
106
97
124
108
95
115
106
97
85
113
101
116
106
96
115
96
124
108
86
104
101
116
124
130
130
130
130
130
130
130
131
108
96
115
106
96
122
120
86
104
84
115
95
100
116
40
89
114
120
122
86
104
85
113
84
102
107
84
115
95
84
106
97
113
85
124
108
115
95
106
97
85
113
115
95
115
98
115
95
115
98
80
117
83
122
89
105
86
104
109
82
103
85
104
82
103
45
56
4
46
10
61
70
35
71
45
56
46
10
70
61
58
57
5
27
64
50
64
5
57
18
27
48
30
57
6
71
8
34
8
71
7
6
57
1
49
64
64
70
61
70
61
10
46
9
71
46
10
3
45
56
56
58
45
30
68
52
51
77
12
42
11
44
41
74
Z
G
Z
E
H
F
H
D
C
B
A
Device 1
126
128
125
83
129
68
33
87
104
109
81
86
104
109
69
36
26
25
86
104
109
87
104
109
127
103
104
86
23.3.デバイステーブル(DGSD)
23.3.Device table(DGSD)
23.3.デバイステーブル(DGSD)
23.3.Device table(DGSD)
23 - 7
CP-742ME PARTS LIST ver03
Ref.23-4
CP-743ME,CP-742ME PARTS LIST ver03
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DGSD0011 1 TABLE ﾃｰﾌﾞﾙ
3 DGSD0101 1 GUIDE ｶﾞｲﾄﾞ
4 DGSD0111 1 GUIDE ｶﾞｲﾄﾞ
5 DGSD0600 2 BKT BKT
6 DGSD0611 2 BKT BKT
7 DGSD0281 1 BKT BKT
8 DGSD0640 2 BKT BKT
9 DGSD0650 1 BKT BKT
10 DGSD0660 4 PIN ｼｬﾌﾄ
11 DGSD0290 1 BKT BKT
12 DCSD1020 1 BKT BKT
13 DGSD0680 1 BKT BKT
14 DGSD0300 1 BKT BKT
15 DGSD0310 1 BKT BKT
18 DGSD0690 1 BLOCK, STOPPER ﾌﾞﾛｯｸ ｽﾄｯﾊﾟ
19 DGSD0700 2 STOPPER ｽﾄｯﾊﾟ
20 DGSD0710 2 COLLAR ｶﾗｰ
22 DGSD1020 1 GUIDE BKT
23 DGSD0380 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
25 DGSD0870 1 BKT, SW BKT SW
26 DGSD0880 1 BKT, SW BKT SW
27 DCSD0622 2 PLATE ﾌﾟﾚｰﾄ
28 DGSD0420 1 BKT, SW BKT SW
29 DGSD0921 1 BKT, SW BKT SW
30 DGSD0751 2 SPRING ｽﾌﾟﾘﾝｸﾞ
31 DGSD0142 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
33 DGSD0910 1 BKT, SW BKT SW
34 DGSD0890 1 DOG ﾄﾞｯｸﾞ
35 DGSD0450 1 BKT BKT
36 DGSD0411 1 BKT BKT
40 DCSD0350 1 STOPPER ｽﾄｯﾊﾟ
41 DCSD0360 2 PIN ﾋﾟﾝ
42 DCSD0370 1 GUIDE ｶﾞｲﾄﾞ
44 DCSD0150 1 DOG ﾄﾞｯｸﾞ
45 DCSD0561 4 HOOK ﾌｯｸ
46 DCSD0571 4 HOOK ﾌｯｸ
47 DCSD0580 1 PIN ﾋﾟﾝ
48 DCSD0590 1 STOPPER ｽﾄｯﾊﾟ
49 DCSD0600 1 PIN, LOCATING ﾋﾟﾝ 位置決め
50 DCSD0610 1 PIN, LOCATING ﾋﾟﾝ 位置決め
51 DCSD0650 1 BKT BKT
52 DCSD0660 1 BKT, SENSOR BKT ｾﾝｻ
54 DCSD0680 4 FLANGE ﾌﾗﾝｼﾞ
55 DCSD0690 4 SHAFT ｼｬﾌﾄ
PARTS LIST CP-743ME,CP-742ME ver03
23 - 8
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
56 DCSD0710 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
57 DCSD0720 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
58 DCSD0771 2 SPRING ｽﾌﾟﾘﾝｸﾞ
59 DCSD0800 4 SCREW, SET ﾈｼﾞ 止め
60 DCSD0830 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
61 DCSD0760 4 STOPPER ｽﾄｯﾊﾟ
62 DCSD1010 1 PLATE, SW ﾌﾟﾚｰﾄ SW
63 DCSD0820 4 SPRING ｽﾌﾟﾘﾝｸﾞ
64 DCSD0891 4 SHIM ｼﾑ t=7.0 注1.Note.1
65 DCSD0881 30 PIN ﾋﾟﾝ
66 DCSD1030 30 ROLLER ﾛｰﾗ
67 K5342W 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-08S(ｼﾛ)
68 S4045F 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX871A
69 S31147 3 SW, PROXIMITY SW 近接 APM-D3A1-05
70 H4429H 4
BEARING, BALL
ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16UU
71 K10911 4 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF10-A
72 K1108H 4 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF4-A
74 S30203 1 SPRING ｽﾌﾟﾘﾝｸﾞ WR6-60
75 H30632 8 BUSHING ﾌﾞｯｼｭ SPB-162220
76 S3148L 1 SW, PHOTOELECTRIC SW 光電 HPJ-D21-L05
77 K4197A 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ 05.10-018-42-10P
80 H5269A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X5L
81 H5271A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X8L
82 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L
83 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
84 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
85 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
86 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
87 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
88 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L
89 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
90 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
91 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
92 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
93 H5311A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X60L
94 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
95 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
96 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
97 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
98 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
99 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
100 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L
101 H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L
102 H5344A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X35L
PARTS LIST CP-743ME,CP-742ME ver03
23 - 9
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
