4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
2 DGQC3220 1 STOPPER ｽﾄｯﾊﾟ
3 DGQC3230 1 BKT, SENSOR BKT ｾﾝｻ
6 DGQC3090 1 BRIDGE ﾌﾞﾘｯｼﾞ
7 DGQC3100 1 BRIDGE ﾌﾞﾘｯｼﾞ
8 DGQC3024 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
9 DGQC3035 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
10 DGQC3110 1 BKT BKT
11 DGQC3120 1 BKT BKT
12 DCQC0710 1 STOPPER ｽﾄｯﾊﾟ
13 DCQC0830 1 STOPPER ｽﾄｯﾊﾟ 薄厚基板対応(ｵﾌﾟｼｮﾝ)
14 ADGQC8040 2 PULLEY ASSY ﾌﾟｰﾘ ASSY 薄厚基板対応(ｵﾌﾟｼｮﾝ)
15 DGQC0690 2 PULLEY ﾌﾟｰﾘ 薄厚基板対応(ｵﾌﾟｼｮﾝ)
16 DGQC3060 1 PLATE ﾌﾟﾚｰﾄ
17 DGQC3130 2 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
24 DGQC3180 1 LEVER ﾚﾊﾞｰ
28 DGQC3290 2 COLLAR ｶﾗｰ
30 DGQC3350 1 BKT BKT
31 DGQC3360 1 SHAFT ｼｬﾌﾄ
33 DGQC3300 1 STOPPER ｽﾄｯﾊﾟ
35 DCQC3390 1 BKT, WIRING BKT 配線
39 DGQC3200 1 BKT BKT
40 DCQC3270 1 COLLAR ｶﾗｰ
41 DCQC3290 1 BKT BKT
43 DCQC3320 1 SHAFT ｼｬﾌﾄ
44 DCQC3330 1 SHAFT ｼｬﾌﾄ
45 DCQC3340 1 SHAFT ｼｬﾌﾄ
46 DCQC3350 1 SHAFT ｼｬﾌﾄ
51 ADGQC8030 1 HANDLE ASSY ﾊﾝﾄﾞﾙ ASSY
54 DCQC0330 2 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ
56 DCQC0720 1 STOPPER ｽﾄｯﾊﾟ
57 DCQC0820 1 STOPPER ｽﾄｯﾊﾟ 薄厚基板対応(ｵﾌﾟｼｮﾝ)
60 DCQC3541 1 BKT, SENSOR BKT ｾﾝｻ
61 DCQC3531 1 BKT BKT
66 CSQC1210 8 WASHER, SPHERICAL ﾜｯｼｬ 球面
67 CSQC1220 8 WASHER, SPHERICAL ﾜｯｼｬ 球面
68 CSQC1230 8 NUT, HEX ﾅｯﾄ 六角
70 MQC1061 2 TENSION PULLEY ASSY ﾃﾝｼｮﾝﾌﾟｰﾘ ASSY
71 ADCQC8030 2 PULLEY ASSY ﾌﾟｰﾘ ASSY 薄厚基板対応(ｵﾌﾟｼｮﾝ)
72 CSQC0570 4 STOPPER ｽﾄｯﾊﾟ
74 MQC1073 1 SEAL ｼｰﾙ
75 MQC1292 4 PULLEY ASSY ﾌﾟｰﾘ ASSY
76 MQC1300 1 SEAL ｼｰﾙ
77 MQC3313 1 GUIDE, CONVEYOR ｶﾞｲﾄﾞ ｺﾝﾍﾞｱ
78 MQC3323 1 GUIDE, CONVEYOR ｶﾞｲﾄﾞ ｺﾝﾍﾞｱ
PARTS LIST CP-743ME,CP-742ME ver03
4 - 2
4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
79 GVC0141 3 COLLAR ｶﾗｰ
80 GVC0320 2 COLLAR ｶﾗｰ
81 GVC0350 4 COLLAR ｶﾗｰ
82 GVC2262 1 SPROCKET ｽﾌﾟﾛｹｯﾄ
83 DGQC3370 1 BKT BKT
84 CLC9051 3 HOLDER ﾎﾙﾀﾞ
85 CLN8690 2 SPROCKET ｽﾌﾟﾛｹｯﾄ
86 IQC6041 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
89 M5063H 2 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6A6ZMR244
90 H4001T 2
HEAD, GEAR
ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1
91 DCQC3550 1 SW, PHOTOELECTRIC SW 光電 DL-S3R
95 H4445A 8
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ
96 S3034A 4 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2-Type
97 S1022A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4
98 T21382 1 CHAIN ﾁｪｰﾝ RS25NP 430ﾘﾝｸ
99 T2026Z 1 CHAIN ﾁｪｰﾝ RS25NP 202ﾘﾝｸ ﾂｷﾞﾃﾘﾝｸﾂｷ
100 T2017A 1 CHAIN ﾁｪｰﾝ RS25NP 62ﾘﾝｸ ｴﾝﾄﾞﾚｽ
101 N1014A 2
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU AN00
102 H4440A 8
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ
103 H4123A 1 BEARING ﾍﾞｱﾘﾝｸﾞ UFL000
105 H4451A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ
107 W10022 2 WASHER ﾜｯｼｬ TL182(NO2)
108 S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13 1-Type
117 H2056A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ ﾟ4X14
118 H2059A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ ﾟ4X20
121 N1124A 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR10
124 T20242 1 CHAIN ﾁｪｰﾝ RS25NP166ﾘﾝｸ
125 K5335A 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU4
131 DGQC3080 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
132 H42945 2 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ SSR15XWY1UUC1+400LH-2
133 DGQC0110 1 PLATE ﾌﾟﾚｰﾄ
134 DGQC0120 1 PLATE ﾌﾟﾚｰﾄ
135 DGQC0260 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
136 DGQC0290 2 BELT ﾍﾞﾙﾄ
137 DGQC0700 2 BELT ﾍﾞﾙﾄ 薄厚基板対応(ｵﾌﾟｼｮﾝ)
138 DGQC0320 2 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ
140 DGQC0340 2 BKT BKT
141 DGQC0350 2 BKT BKT
146 DGQC0420 1 SHAFT ｼｬﾌﾄ
153 DGQC0220 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
154 DGQC0230 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
157 H4444T 4 BEARING MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-950ZZ
158 MQC1181 2 COLLAR ｶﾗｰ
159 DGQC0570 2 COLLAR, BEARING ｶﾗｰ ﾍﾞｱﾘﾝｸﾞ
PARTS LIST CP-743ME,CP-742ME ver03
4 - 3
4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
160 DGQC0580 2 BKT BKT
161 DGQC0590 2 PULLEY ﾌﾟｰﾘ
162 DGQC0600 2 BOLT ﾎﾞﾙﾄ
163 DGQC0610 1 BKT BKT
164 Y3075A 2 UNION ﾕﾆｵﾝ KQ2U06-00
166 DGQC0140 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
167 DGQC0160 2 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
173 H5281A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X25L
174 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
176 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
177 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
179 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L
180 H5296H BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X55L
181 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
182 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
183 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
184 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
186 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
185 H5319H BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X8L
186 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
187 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
188 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
189 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
190 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
191 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
192 H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L
193 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
195 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
196 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
197 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
198 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
199 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
201 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
202 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
205 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L
206 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L
207 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-6-H
210 K5359E
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿       
M4X8L
211 N4028A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M4X6L
212 N4026A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M4X4L
217 K52564
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X5L
218 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X10L
219 K5261H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X12L
221 N1082A
NUT, HEX
ﾅｯﾄ 六角         
M5 P=0.8
PARTS LIST CP-743ME,CP-742ME ver03
4 - 4
4.1.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.1.Out conveyor(DGQC)
