32.6.銘板,ｼｰﾙ(DGWM)
32.6.Nameplate,Seal(DGWM)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
58 DCWM0610 1 SEAL ｼｰﾙ French
59 DCWM0620 2 SEAL ｼｰﾙ French
60 DCWM0630 1 NAMEPLATE 銘板 French
61 DCWM0640 1 SEAL ｼｰﾙ French
62 DCWM0650 1 SEAL ｼｰﾙ French
63 DGWM0730 1 NAMEPLATE, SOL 銘板 SOL French
64 DCWM0670 1 NAMEPLATE, SOL 銘板 SOL French(Option)
65 DGWM0740 1 NAMEPLATE, SOL 銘板 SOL French
66 DGWM0750 1 PIN 銘板 SOL French
67 DCWM0700 1 NAMEPLATE, SOL 銘板 SOL French
68 DCWM0710 1 NAMEPLATE 銘板 French
69 DCWM0722 1 NAMEPLATE, SOL 銘板 SOL French
70 DGWM0710 1 NAMEPLATE, SOL 銘板 SOL French
71 DGWM0720 1 NAMEPLATE, SOL 銘板 SOL French
72 DCWM0750 1 SEAL ｼｰﾙ French
73 DCWM0760 1 NAMEPLATE, SOL 銘板 SOL French
74 IPK5500 1 SEAL ｼｰﾙ French
75 IPK5600 1 GUIDE ｼｰﾙ French
PARTS LIST CP-743ME,CP-742ME ver03
32 - 12
32.6.銘板,ｼｰﾙ(DGWM)
32.6.Nameplate,Seal(DGWM)
A
139
x5
17
20
14
13
12
15
15
10
8
9
7
18
19
16
21
21
11
6
5
4
2
3
1
33.エアー機器(DGPI)
33.Air device(DGPI)
33.エアー機器(DGPI)
33.Air device(DGPI)
33 - 1
CP-743ME,CP-742ME PARTS LIST ver03
33.ｴｱｰ機器(DGPI)
33.Air device(DGPI)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 H3149A 1
PLUG, COUPLER
ﾌﾟﾗｸﾞ ｶﾌﾟﾗ 20PM
2 H1059T 1 VALVE, BALL ﾊﾞﾙﾌﾞ ﾎﾞｰﾙ RP-LL-3/8
3 H3075A 1
BUSHING
ﾌﾞｯｼｭ 3/8X1/4
4 H1282A 1
PIPE, DOUBLE ENDED
ﾊﾟｲﾌﾟ 両口         
3/8X25
5 A4081A 1
ELBOW, DIFFERENT DIAMETERS
ｴﾙﾎﾞ 異径         
3/8X1/4
6 N20291 1 NIPPLE ﾆｯﾌﾟﾙ 1/4
7 H30297 1
FILTER REGULATOR
ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AW3000-02-BD
8 S3059Y 1
SPACER
ｽﾍﾟｰｻ Y30(29.5)
9 S4016R 1
SEPARATOR, MIST
ｾﾊﾟﾚｰﾀ ﾐｽﾄ AFM3000-02-D
10 Y3079T 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L08-02S
11 H3255A 1 BUSHING ﾌﾞｯｼｭ RBF
12 GXA0110 1 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管
13 K53710 4 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ EC6-PT1/8
14 A4147A 4 ELBOW 32 EL8-PT1/8
15 A4146A 2 ELBOW ｴﾙﾎﾞ         EL8-PT1/4
16 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ AP-43
17 H5295A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X35L
18 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X12L
19 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
20 A3034A 1 PLUG ﾌﾟﾗｸﾞ PT 1/8
21 A1038Y 1 AMPLIFIER ｱﾝﾌﾟ AP-40Z
PARTS LIST CP-743ME,CP-742ME ver03
33 - 2
33.ｴｱｰ機器(DGPI)
33.Air device(DGPI)
