28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
47 DCAF0550 1 BKT BKT
48 DGAF0490 1 BKT BKT
49 DGAF0110 2 FRAME ﾌﾚｰﾑ
50 DGAF0890 1 BKT BKT
51 DGAF0910 1 BKT BKT
52 DGAF0252 1 RAIL ﾚｰﾙ
53 DGAF0282 2 RAIL ﾚｰﾙ
54 DGAF0900 1 BKT BKT
55 DGAF0920 1 BKT BKT
56 DGAF0242 1 RAIL ﾚｰﾙ
57 DGAF0360 1 BKT BKT
58 DGAF0370 1 BKT BKT
59 DCAF0630 22 BKT BKT
60 DCAF0940 1 BKT BKT
61 DCAF0410 1 BKT BKT
62 DCAF0400 4 BKT BKT
63 DGAF0510 2 BKT, SW BKT SW
64 DGAF0521 1 PLATE, SW ﾌﾟﾚｰﾄ SW
65 DGAF0350 1 BKT, SW BKT SW
66 DGAF0480 1 BKT, SW BKT SW
67 DGAF0531 1 PLATE, SW ﾌﾟﾚｰﾄ SW
68 DCAF0390 2 LOCATOR 当金
70 DGAF0970 1 COVER 蓋
71 DGAF0440 4 SLIDER ｽﾗｲﾀﾞ
72 T5005T 4 HANDLE 取手 THA-132-3-3473
73 M1010K 8 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-75-1181
75 S3193K 4 SW, LIMIT SW ﾘﾐｯﾄ D4DL-1DFG-B
76 S3193N 4 SW, LIMIT SW ﾘﾐｯﾄ D4DS-K1
77 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
78 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
79 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
80 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
81 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
82 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
83 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L
84 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
85 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
86 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
87 H5301A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L
88 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
90 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L
91 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
92 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L
93 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X20L
94 H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L
PARTS LIST CP-743ME,CP-742ME ver03
28 - 3
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
95 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
96 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
97 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
98 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
99 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
100 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
101 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
102 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
103 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
104 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
105 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
106 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
107 K5215A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X10L
108 K51721
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X5L
109 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L
111 K5260A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X8L
112 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L
113 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
114 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8
115 ADCAF8050 1 PLATE, ACRYLIC ﾌﾟﾚｰﾄ ｱｸﾘﾙ
116 DCAF0220 1 BKT BKT
117 ADGAF8050 2 PLATE ﾌﾟﾚｰﾄ
118 DGAF0420 2 BKT BKT
119 DGAF0311 1 BKT BKT
120 DGAF0320 1 BKT BKT
121 DGAF0330 1 BKT BKT
122 DGAF0340 1 BKT BKT
123 DGAF0220 1 FRAME ﾌﾚｰﾑ
124 DGAF0230 1 FRAME ﾌﾚｰﾑ
125 DGAF0450 1 BKT BKT
126 DGAF0460 2 COVER 蓋
127 DGAF0470 2 COVER 蓋
128 DGAF0850 1 BKT BKT
129 DGAF0860 1 BKT BKT
130 DCAF0670 4 BKT BKT
131 DGAF0500 1 BKT BKT
132 DGAF0542 8 BLOCK ﾌﾞﾛｯｸ
133 H5263C
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X16L
134 H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L
136 H5295A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X35L
137 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
138 K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L
139 ADCAF8071 2 BKT BKT
140 DCAF0781 2 BKT BKT
141 DCAF0790 2 PLATE ﾌﾟﾚｰﾄ
PARTS LIST CP-743ME,CP-742ME ver03
28 - 4
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
142 DCAF2010 2 BKT BKT
143 DCAF2020 2 BKT BKT
144 DCAF0980 2 SPACER ｽﾍﾟｰｻ
145 DCAF0990 2 BKT BKT
146 MPZ6220 8
WASHER
ﾜｯｼｬ
147 WWM0210 (1) SEAL ｼｰﾙ
148 H5137S 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ UNST6-30
149 A1002Z 2 LEG, RUBBER 脚 ｺﾞﾑ K18(No.7217)
150 W1040 WASHER, FLAT ﾜｯｼｬ 平 1W-3
153 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L
154 DCAF2050 4 SEAL ｼｰﾙ
155 DCWM0250 1 SEAL ｼｰﾙ Japanese(Ref.32-7)
156 DCWM0450 1 SEAL ｼｰﾙ English(Ref.32-9)
157 DCWM0650 1 SEAL ｼｰﾙ French(Ref.32-11)
158 DGAF0930 1 BKT BKT
159 DGAF5940 2 BKT BKT
160 H5137S 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ
161 N1086A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0
162 DCGC0470 1 DISPLAY, LIQUID CRYSTAL ﾃﾞｨｽﾌﾟﾚｲ 液晶 743E
163 ZG827DCEM9850 1 BOX, SERVO BOX ｻｰﾎﾞ 743E
注1.注1の部品をｾｯﾄで購入することができます｡ADGAF8081ﾌﾚｰﾑで注文してください｡
Note.1:Note.1 items can be purchased separately or as set(ADGAF8081 Frame).
注2.注2の部品をｾｯﾄで購入することができます｡ADGAF8091ﾌﾚｰﾑで注文してください｡
Note.2:Note.2 items can be purchased separately or as set(ADGAF8091 Frame).
PARTS LIST CP-743ME,CP-742ME ver03
28 - 5
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
