24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
52 DCPA1580 2 GEAR, PINION ｷﾞﾔ ﾋﾟﾆｵﾝ
53 DCPA0490 1 GEAR, BEVEL ｷﾞﾔﾍﾞﾍﾞﾙ
56 DCPA0500 1 KEY ｷｰ
57 DCPA0260 1 SCREW, ADJUSTING ﾈｼﾞ 調整
60 DCPA0280 1 BKT, ADJUSTING BKT 調整
61 DCPA0520 1 COLLAR ｶﾗｰ
62 DCPA0451 1 COVER 蓋
64 DCPA1410 1 SHAFT ｼｬﾌﾄ
65 DCPA1440 1 HOUSING ﾊｳｼﾞﾝｸﾞ
66 DCPA1500 2 NUT ﾅｯﾄ
67 DCPA1520 2 COLLAR ｶﾗｰ
68 DCPA1530 2 SPRING ｽﾌﾟﾘﾝｸﾞ
69 DCPA1610 1 SPRING ｽﾌﾟﾘﾝｸﾞ
70 DCPA1420 1 SHAFT ｼｬﾌﾄ
71 DCPA1450 1 HOUSING ﾊｳｼﾞﾝｸﾞ
72 DCPA1510 4 BLOCK 駒
73 DCPA1460 2 COVER ｶﾊﾞｰ
77 DCPA0300 1 PLATE ﾌﾟﾚｰﾄ
78 DCPA0320 1 BKT BKT
79 DCPA0330 2 BKT BKT
80 DCPA0390 1 SHAFT ｼｬﾌﾄ
81 DCPA1270 1 SHAFT ｼｬﾌﾄ
82 DCPA0340 1 BKT BKT
83 DCPA0380 3 COLLAR ｶﾗｰ
84 DCPA1290 1 BKT BKT
85 DCPA1150 1 HOLDER ﾎﾙﾀﾞ
92 DCPA0082 1 BKT, MOTOR BKT ﾓｰﾀ
93 DCPA0840 1 BKT BKT
100 DCPA1140 1 BKT BKT
111 DCPA0890 1 PLATE ﾌﾟﾚｰﾄ
112 DCPA0861 2 PIN, LOCATING ﾋﾟﾝ 位置決め
114 DCPA1640 1 PLATE ﾌﾟﾚｰﾄ
115 DGPA0060 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
116 DCPA1200 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
117 DCPA1310 1 BKT BKT 注1.Note.1
118 DCPA1320 1 BKT BKT 注1.Note.1
119 DCPA0430 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ 注1.Note.1
120 DCPA0440 1 HOUSING ﾊｳｼﾞﾝｸﾞ 注1.Note.1
140 DCPA1031 1 BKT BKT
141 DCPA0400 1 SHAFT ｼｬﾌﾄ
142 DCPA0880 2 PIN, LOCATING ﾋﾟﾝ 位置決め
143 DCPA0870 2 PIN, LOCATING ﾋﾟﾝ 位置決め
146 S1012A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ RTW52
147 H4189Y 2
BEARING
ﾍﾞｱﾘﾝｸﾞ 6205ZZ
PARTS LIST CP-743ME,CP-742ME ver03
24 - 3
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
148 H4181A 6
BEARING
ﾍﾞｱﾘﾝｸﾞ 6003ZZ
149 S1036A 3
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW17
153 H4232X 4 BEARING ﾍﾞｱﾘﾝｸﾞ HR32006XJP5
154 S1039A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW25
156 S40443 4 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770A
157 N1021Z 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR30
158 H4420T 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ GK35X40X26.8XS
159 H4356A 3
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2525DU
160 H4349A 1
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2015DU
161 H4346A 2
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1815DU
162 N1019H 2
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU AN04
164 S31207 2 SW, PHOTOELECTRIC SW 光電 EE-SX771A
165 K1001T 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ LAD-20C-4X6
174 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
182 H4193T 4 BEARING ﾍﾞｱﾘﾝｸﾞ 6305ZZ
183 DCPA0470 4 SEAL ｼｰﾙ
187 WPA1300 3 KEY ｷｰ
188 WPA0351 1 WASHER ﾜｯｼｬ
189 WPA1642 1 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板
190 WPA1650 1 SCREW ﾈｼﾞ
191 WPA1681 1 BKT BKT
192 WPA1732 1 GUIDE ｶﾞｲﾄﾞ
194 WPA1771 2 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板
195 WPA1750 1 PLATE ﾌﾟﾚｰﾄ
196 WPA1740 1 PLATE ﾌﾟﾚｰﾄ
198 S31970 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-A501
199 S31971 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-Z01
202 DCPA1090 1 SCALE ﾒﾓﾘ
205 DCPA0172 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ
209 H52680 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M02.5X015L
210 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M
219 DCPA0850 1 BKT BKT
220 DCPA1250 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
221 DCPA1650 1 BKT BKT
222 DCPA1660 1 HANDLE ﾊﾝﾄﾞﾙ
223 DCPA1670 1 BKT BKT
224 SAM6452 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ
225 SAM6503 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ
227 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
228 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
229 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
232 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
233 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
234 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
PARTS LIST CP-743ME,CP-742ME ver03
24 - 4
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
235 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
237 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
238 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
239 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
240 H5307A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X40L
241 H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X10L
242 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L
243 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L
244 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L
245 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L
246 H5340A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X15L
247 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X20L
248 H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L
249 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L
250 H5344A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X35L
251 H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X40L
252 H5360A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X25L
253 H5364A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X45L
255 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
256 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
257 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
258 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
259 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
260 W1026A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
261 W1029A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M
262 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
264 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8
265 W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10
266 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
267 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
268 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
269 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H
270 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/MX1.6X17(1W-8)
271 K5357T
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M3X8L
272 H5214A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M10X45L
274 N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X5L
275 N4036A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M5X5L
276 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
277 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
279 N1083A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 3ｼｭ
282 N1099T
NUT, HEX
ﾅｯﾄ 六角
M16 P=1.5
283 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
284 N1089A
NUT, HEX
ﾅｯﾄ 六角
M8 P=1.25
286 DCPA0510 1 COLLAR ｶﾗｰ
