4.2.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.2.Out conveyor(DGQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
226 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L
227 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
228 K5200A SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M2X3L ﾕﾆｸﾛﾒｯｷ
229 DGQC0560 1 GUIDE ｶﾞｲﾄﾞ
231 ADGQC8010 1 BKT ASSY BKT ASSY
232 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
233 N4021A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X6L
PARTS LIST CP-743ME,CP-742ME ver03
4 - 9
4.2.ｱｳﾄｺﾝﾍﾞｱ(DGQC)
4.2.Out conveyor(DGQC)
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
X5
50
50
50
50
50
50
50
50
44
68
138
121
104
121
121
134
108
122
104
121
104
121
129
103
129
103
129
103
130
107
138
133
138
133
133
138
133
138
133
138
133
138
138
133
129
104
104
129
129
104
104
129
130
107
103
129
107
130
133
138
129
103
129
103
130
107
129
103
129
103
121
134
121
104
121
104
121
104
105
121
125
125
121
105
138
121
122
108
70
71
71
71
70
70
70
71
84
83
84
83
145
5
145
5
4
3
85
85
34
87
35
86
48
47
50
50
68
2
88
43
44
42
41
86
35
87
34
61
61
43
88
44
44
42
41
49
47
60
50
85
87
35
86
34
85
87
35
86
50
1
CP-743ME,CP-742ME PARTS LIST ver03
5 - 1
5.1.In carrier(DGQK)
5.1.インキャリア(DGQK)
5.1.In carrier(DGQK)
5.1.インキャリア(DGQK)
5.1.ｲﾝｷｬﾘｱ(DGQK)
5.1.In carrier(DGQK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DGQK0080 1 CLAMPER ｸﾗﾝﾊﾟ
2 DGQK0030 1 CLAMPER ｸﾗﾝﾊﾟ
3 DGQK0090 1 PLATE ﾌﾟﾚｰﾄ
4 DGQK0040 1 PLATE ﾌﾟﾚｰﾄ
5 DGQK0140 2 PLATE ﾌﾟﾚｰﾄ
34 CSQC4160 3 HOLDER ﾎﾙﾀﾞ
35 CSQC4171 4 PIN, PIVOT ﾋﾟﾝ 支点
41 CSQC4290 2 BKT BKT
42 CSQC4300 2 BLOCK ﾌﾞﾛｯｸ
43 CSQC4310 2 PIN ﾋﾟﾝ
44 CSQC4321 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
47 CSQC4521 2 DOG ﾄﾞｯｸﾞ
48 CSQC4531 1 DOG ﾄﾞｯｸﾞ
49 DCQK0300 1 DOG ﾄﾞｯｸﾞ
50 CSQC4590 12 BKT BKT
60 CSQC4880 1 HOLDER ﾎﾙﾀﾞ
61 CSQC4920 2 DOG ﾄﾞｯｸﾞ
68 CSQC5371 42 JAW 爪
70 ADCQK8010 38 PIN, CLAMP ﾋﾟﾝ ｸﾗﾝﾌﾟ
71 ADCQK8020 4 PIN, CLAMP ﾋﾟﾝ ｸﾗﾝﾌﾟ
83 S30205 12 SPRING ｽﾌﾟﾘﾝｸﾞ WR6-25
84 H2053A 12
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 3ﾟX25L
85 H2031A 4
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 3ﾟX14L
86 W1001Y 4
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ 70W-0815
87 H4403A 4
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA810Z
88 S30207 2 SPRING ｽﾌﾟﾘﾝｸﾞ AWS4-20
103 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L
104 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
105 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
107 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
108 H5169A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
112 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L
116 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L
121 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
122 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
125 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
128 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
129 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
130 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
133 N4024A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X12L
134 K5255H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X5L
138 N1076A
NUT, HEX
ﾅｯﾄ 六角
M3 P=0.5
140 N1077H NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 3ｼｭ
145 DGQK0150 2 PLATE ﾌﾟﾚｰﾄ .
PARTS LIST CP-743ME,CP-742ME ver03
5 - 2
5.1.ｲﾝｷｬﾘｱ(DGQK)
5.1.In carrier(DGQK)
