42.ｶﾊﾞｰ前部(743ME)(DGPZ)
42.Cover front(743ME)(DGPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
97 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L
98 N1089A
NUT, HEX
ﾅｯﾄ 六角         
M8 P=1.25
99 N1076A
NUT, HEX
ﾅｯﾄ 六角         
M3
100 W1041A WASHER, FLAT ﾜｯｼｬ 平 1W-4
102 H5263C BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X16L
103 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
104 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
105 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
106 H5343A BOLT, HEX ﾎﾞﾙﾄ 六角 M8X30L
107 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
108 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
109 ADGPZ8170 1 COVER,FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME Use only when no external parts monitor.
110 DCPZ1550 1 BKT BKT 743ME
111 DCGC0470 1 DISPLAY, LIQUID CRYSTAL ﾃﾞｨｽﾌﾟﾚｲ 液晶 743ME
112 DCPZ1500 1 SPACER ｽﾍﾟｰｻ 743ME
113 DCPZ1510 1 BKT BKT 743ME
114 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
115 DCPZ1520 1 BKT BKT 743ME
PARTS LIST CP-743ME,CP-742ME ver03
42 - 4
42.ｶﾊﾞｰ前部(743ME)(DGPZ)
42.Cover front(743ME)(DGPZ)
x30
21
20
19
5
7
6
10
9
8
22
28
83
82
84
23
29
27
26
25
24
62
30
69
66
64
61
63
67
68
65
51
47
39
38
36
35
37
37
99
98
100
50
46
49
48
52
53
45
70
80
79
81
80
79
81
83
82
84
31
91
89
90
4
54
57
60
56
59
55
58
71
32
33
34
74
73
75
72
78
76
77
Ref.29-1
Ref.31-1
88
85
85
87
85
86
87
87
85
96
95
97
93
92
94
93
93
92
92
94
凡例
Example
94
44
44
43
42
41
40
11
17
12
18
16
15
14
14
14
13
18
101
3
2
1
43.防音シール(743ME)(DGPZ)
43.Noise redaction seal(743ME)(DGPZ)
43.防音シール(743ME)(DGPZ)
43.Noise redaction seal(743ME)(DGPZ)
43 - 1
CP-743ME,CP-742ME PARTS LIST ver03
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 ADGPZ8052 1 COVER ｶﾊﾞｰ
2 DGPZ0023 1 COVER ｶﾊﾞｰ
3 DGPZ0532 1 SEAL ｼｰﾙ
4 ADGPZ8062 1 COVER ｶﾊﾞｰ
5 DGPZ0032 1 COVER ｶﾊﾞｰ
6 DCPZ0220 1 SEAL ｼｰﾙ
7 DGPZ0522 1 SEAL ｼｰﾙ
8 ADGPZ8072 1 COVER ｶﾊﾞｰ
9 DGPZ0042 1 PIN ｶﾊﾞｰ
10 DGPZ0510 1 SEAL ｼｰﾙ
11 ADGPZ8130 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME
12 DGPZ1540 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
13 DGPZ2130 1 SEAL ｼｰﾙ 743ME
14 DGPZ2120 3 SEAL ｼｰﾙ 743ME
15 DGPZ1490 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME Use only when no external parts monitor.
16 DCPZ1860 1 SEAL ｼｰﾙ 743ME Use only when no external parts monitor.
17 DGPZ2010 1 SEAL ｼｰﾙ
18 DGPZ2150 2 GUIDE ｼｰﾙ 743ME
19 ADGPZ8091 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
20 DGPZ1171 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
21 DGPZ2080 1 SEAL ｼｰﾙ
22 ADGPZ8102 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
23 DGPZ1182 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
24 DGPZ2040 1 SEAL ｼｰﾙ
25 DGPZ2050 1 SEAL ｼｰﾙ
26 DGPZ2060 1 SEAL ｼｰﾙ
27 DGPZ2070 1 SEAL ｼｰﾙ
28 ADGPZ8111 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
29 DGPZ1192 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
30 DGPZ2031 1 SEAL ｼｰﾙ
31 ADGAF8100 1 COVER ｶﾊﾞｰ
32 DCAF0120 1 COVER ｶﾊﾞｰ
33 DCAF1160 1 SEAL ｼｰﾙ
34 DCAF1170 1 SEAL ｼｰﾙ
35 ADGAF8110 1 COVER, REAR ｶﾊﾞｰﾘﾔ-
36 DGAF0160 1 COVER ｶﾊﾞｰ
37 DGAF1060 2 SEAL ｼｰﾙ
38 DGAF1040 1 SEAL ｼｰﾙ
39 DGAF1160 1 SEAL ｼｰﾙ
PARTS LIST CP-743ME,CP-742ME ver03
43 - 2
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
