8.1.基板ｸﾗﾝﾌﾟ(DGSS) 8.1.Board clamping unit(DGSS) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 62 CSSS0960 1 WASHER ﾜｯｼｬ 63 CSSS1040 1 COLLAR ｶﾗｰ 64 CSSS1051 1 SPRING ｽﾌﾟﾘﾝｸﾞ 73 …
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DGSS0580 1 RAIL ﾚｰﾙ
2 DGSS0022 1 RAIL ﾚｰﾙ
3 S3084A 2 SLEEVE ｽﾘｰﾌﾞ 40-13
4 DGSS0150 1 BKT BKT
5 DGSS0101 1 BKT BKT
6 DGSS0091 1 BKT BKT
7 DGSS0050 1 HOLDER ﾎﾙﾀﾞ
8 DGSS0040 1 HOLDER ﾎﾙﾀﾞ
9 DGSS0180 1 BKT BKT
10 DGSS0260 1 SEAL ｼｰﾙ
11 DGSS0560 1 WASHER ﾜｯｼｬ
12 DGSS0320 1 BKT, SENSOR BKT ｾﾝｻ
13 DGSS0330 1 DOG ﾄﾞｯｸﾞ
14 DGSS0550 46 JAW 爪
15 DGSS0540 1 BKT BKT
16 DGSS0290 1 BKT BKT
20 DGSS0210 1 COLLAR ｶﾗｰ
21 DGSS0190 1 COLLAR ｶﾗｰ
22 DGSS0200 1 COLLAR ｶﾗｰ
23 DGSS0480 1 BKT, SENSOR BKT ｾﾝｻ HELPS
24 DGSS0490 1 BKT, SENSOR BKT ｾﾝｻ HELPS
25 DGSS0300 1 BKT BKT
26 DGSS0080 3 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
27 DGSS0060 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
28 DGSS0070 1 BKT BKT
29 DGSS0220 1 LEVER ﾚﾊﾞｰ
30 DGSS0231 1 LEVER ﾚﾊﾞｰ
31 DGSS0240 1 LEVER ﾚﾊﾞｰ
32 DGSS0250 1 LEVER ﾚﾊﾞｰ
33 DGSS0161 1 SHAFT ｼｬﾌﾄ
34 DGSS0172 1 SHAFT ｼｬﾌﾄ
37 DGSS0380 1 BKT, WIPING BKT 配線
40 DGSS0340 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
48 DGSS0390 4 CLAMPER ｸﾗﾝﾊﾟ
50 DCSS0250 2 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
52 AWSS8710 2 PISTON ﾋﾟｽﾄﾝ
53 CSSS0121 3 PIN ﾋﾟﾝ
54 CSSS1001 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
55 CSSS0291 2 COLLAR ｶﾗｰ
56 CSSS0970 1 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ
57 CSSS0111 3 BOLT ﾎﾞﾙﾄ
58 CSSS1400 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動
59 CSSS1291 1 BKT, HOLDER BKT ﾎﾙﾀﾞ
60 CSSS0730 1 SPACER ｽﾍﾟｰｻ
61 CSSS0951 1 WASHER ﾜｯｼｬ
PARTS LIST CP-743ME,CP-742ME ver03
8 - 2
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
62 CSSS0960 1 WASHER ﾜｯｼｬ
63 CSSS1040 1 COLLAR ｶﾗｰ
64 CSSS1051 1 SPRING ｽﾌﾟﾘﾝｸﾞ
73 CSSS0141 4 WASHER ﾜｯｼｬ
84 CSSS0130 1 WASHER ﾜｯｼｬ
85 CSSS0150 1 WASHER ﾜｯｼｬ
86 CSSS0170 41 COLLAR ｶﾗｰ
87 CSSS0191 1 WASHER ﾜｯｼｬ
88 CSSS0200 1 WASHER ﾜｯｼｬ
89 CSSS0210 1 WASHER ﾜｯｼｬ
90 CSSS0321 2 SEAL ｼｰﾙ
91 CSSS1330 46 RETAINER 押え
92 YSS0540 2 WASHER ﾜｯｼｬ
93 YSS0570 2 SPRING ｽﾌﾟﾘﾝｸﾞ
94 WSS5300 2 STOPPER ｽﾄｯﾊﾟ
95 A40682 6
ELBOW
ｴﾙﾎﾞ M-5HL-6
96 K5077A 4
CONNECTOR
ｺﾈｸﾀ M-5J
97 K5345D 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-06S(ｼﾛ)
104 H4401A 1
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA69Z
106 S1023A 6
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-5
107 S4045C 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX870A
108 S4032T 2
SENSOR
ｾﾝｻ UM-T50TV HELPS
109 N1067A 1 NUT, U ﾅｯﾄ U M6X1.0
110 Y3079N 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5
111 Y3086Y 4
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQ2S06-M5
113 H3119A 2 PLUG ﾌﾟﾗｸﾞ PF
114 S2147A 2
JOINT
ｼﾞｮｲﾝﾄ BF6
115 H4402D 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA79Z
116 H4386A 2 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA0815Z
117 H4128R 2 BEARING ﾍﾞｱﾘﾝｸﾞ L-1790
118 W10012 2 WASHER ﾜｯｼｬ 70W-1000
119 W1001Y 1 WASHER ﾜｯｼｬ 70W-0815
120 R2074C 1 RING, LOCKING ﾘﾝｸﾞ 締結 UM-6X18
121 H1167H 2
PACKING
ﾊﾟｯｷﾝ MY-24
122 H1162T 2
PACKING
ﾊﾟｯｷﾝ MY-7
130 H5268T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.5X6L
131 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L
132 K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L
133 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
134 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
135 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
136 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
137 H5281A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X25L
138 K5359H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M4X10L
140 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
PARTS LIST CP-743ME,CP-742ME ver03
8 - 3
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
141 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
142 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
143 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
144 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
145 H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L
146 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
147 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
148 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
149 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M
150 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
151 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
152 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
153 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
154 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
155 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
156 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
157 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
158 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
159 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
160 N1081T
NUT, HEX
ﾅｯﾄ 六角
M4 3ｼｭ
161 N1086A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 3ｼｭ
162 DGSS0270 2 LOCATR 当金
163 DGSS0520 1 BKT BKT
164 DCSS0420 1 GUIDE ｶﾞｲﾄﾞ
165 DCSS0430 1 GUIDE ｶﾞｲﾄﾞ
166 H5264T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2X4L
167 H5293A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X25L .
PARTS LIST CP-743ME,CP-742ME ver03
8 - 4
