维修服务治工具清单
3
第 16 章. 维修服务治工具清单
16.1. 维修服务治工具清单
NO TOOL NAME PART NO IMAGE REMARK
1
Calibration
Plate Assy
J90681005A
SM411
+CN400 Nozzle
(J90551072A)
2
Light Mapping
Tool Assy-Fly-Odd
J90551084A
3
Nozzle Holder
Slot Setting Jig
J8305016A
Pitch 15mm
4
Tension gage for z
belt - maker : unitta
- spec: u507
StandardTool
5
Blow Setting
Measurement
J6710006A
6
Feeder Station
Alignment for
SM Feeder
J8307001A
Advanced High Speed Flexible Mounter
4
NO TOOL NAME PART NO IMAGE REMARK
7
Z Phase Encoder
Setting Calble
J8100156A
8
Panasonic Amp data
cable
TO04-
000024
9
Z AMP Parameter
Download Cable
J91672801A
10 Z Phase Indicator -
Z1 (Z) : CPU0
Z2 (Z) : CPU1
(Head AMP LED
Check)
Advanced High Speed Flexible Mounter
SM-系列
SM481
Service Manual
(Recovery CD)
警
告
为了安全起见请在使用此设备前务必阅读本应用说明书。
未接受本设备 C/S 教育的人员请勿任意拆卸、组装。
