SW 703 Downloading a Recipe - Successful Recipe Sent :
83
Successful Recipe Sent
1. The name of the Setup, Recipe and Board will appear
on each SIPLACE machine if the download is
successful.
SW 703 Downloading a Recipe - Unsuccessful Recipe Send :
84
Unsuccess ful Recipe Send
1. If the is any problem with the download a message
will appear to notify you.
The most common reason is that a change is required for
the nozzle changer configuration.
NOTICE! If any other message appears then
notify your supervisor.
SW 703 Downloading a Recipe - Changing the nozzle changer setup. :
85
Changing t he nozzle change r setup.
1. Select the ‘Locations’ icon.
2. The nozzle change icon will be shown in red, click on
the icon to enter the menu.
