00197214_IM_SupportMediaV1.15_EN.pdf - 第13页

Support Media V1.15 10/2013 Edition

12

Release

R30

R40

SuP40

R50

SuP50

R60

Support Media

V1.8

V1.9

V1.11

V1.12

V1.13

V1.14

V1.15

SQL 2008 SP 1 Express Update

1

X

-

SQL 2008 SP 2 Express Update

X

*

SQL 2008 SP 3 Express Update

X

SQL 2008 R2 Express with Tools

X

*

SQL 2008 R2 SP 1 Express with

Tools

X

*

SQL 2008 R2 SP 1 Express

Update

X

*

SQL 2008 R2 SP 2 Express with

Tools

X

SQL 2008 R2 SP 2 Express

Update

X

SQL 2012 Express with Tools

*

SQL 2012 SP 1 + CU 2 Express

with Tools

2

-

SQL 2012 SP 1 Express Update

*

SQL 2012 SP 1 CU 2 Express

Update

2

-

Release

R30

R40

SuP40

R50

SuP50

R60

Support Media

V1.8

V1.9

V1.11

V1.12

V1.13

V1.14

V1.15

SQL Server 2005 SP 1 Update

X

*

SQL Server 2005 SP 2 Update

X

*

SQL Server 2005 SP 3 Update

X

*

SQL Server 2005 SP 4 Update

X

*

SQL Server 2008 SP 1 Update

1

X

-

SQL Server 2008 SP 2 Update

X

*

SQL Server 2008 SP 3 Update

*

SQL Server 2008 R2 SP 1 Update

*

SQL Server 2008 R2 SP 2 Update

*

SQL Server 2012 SP 1 Update

*

SQL Server 2012 SP 1 CU 2

Update

2

-

1

We had to modify this package and integrate the cumulative update KB977443. This was required

for proper installation on Windows 7 / Windows Server 2008R2. Also see

http://support.microsoft.com/?id=kb;en-us;975055 for a description of the problem.

2

SQL 2012 SP 1 has a critical bug (KB2793634) which requires us to install Cumulative Update 2

(CU2).

Support Media V1.15 10/2013 Edition

13

Release

R30

R40

SuP40

R50

SuP50

R60

Support Media

V1.8

V1.9

V1.11

V1.12

V1.13

V1.14

V1.15

Windows Imaging Component

*

Active Sync 3.7.1

X

-

Active Sync 4.5

X

-

Windows Mobile Device Center 6.1

X

-

WinHlp32 Hotfix for Vista/W2008

X

-

PowerShell V1 for XP/W2003/Vista

X

*

PowerShell V2 for Vista/W2008

*

SQL XML 4.0 SP 1

X

Root Certificates Update December

2012

X

Adobe Reader 7.0

X

Adobe Reader 9.3

X

Adobe Reader 10.1

X

Microsoft MSMQ Hotfix 2554746

X

4.4 Download of required, but not distributed software

The Support Media Prerequisite Analyzer offers multiple ways of downloading and installing

software components.

CAUTION

Legal changes regarding redistribution

The redistribution right is affecting the delivery through digital media like DVD as

well as manual delivery through ASM Assembly Systems personnel.

The following chapter describes the available options exemplarily.

4.4.1 Download options of Prerequisite Analyzer

In Prerequisite Analyzer on the Pending Actions Summary page, before installation of Prerequisites

takes place, the media will be checked for the availability of all required software packages. If at

least one of the required packages is missing, you will get one of the following two dialogs, with the

options sorted by relevance. In this chapter, we give you a basic overview of the options available.

Support Media V1.15 10/2013 Edition

14

Figure 4-2: Unavailable Installation Packages – No Additional Software Search Folder defined

► Click the Specify Search Folder button to select a (local) folder to search for missing software

packages.

► Click the button Download and install manually to show the list of missing software packages

together with information and links for manual download and installation.

► Click the button Download offline if you don’t have web- access from your computer and want

to download the missing packages using another computer with web-access.

NOTICE

Only local drives supported

Due to security restrictions of some operating systems, it is not possible to select

a network-based Additional Software Search Folder.

Only local folders or locally mapped USB drives are allowed.

Of course, you may copy all the files from the network drive to a local folder to

use them.

After you once selected the Additional Software Search Folder you get the following dialog if

required software packages are still not found.
