Support Media V1.15 10/2013 Edition
45
5.1.26 OIS / Monitoring Service
The following rules are especially for Microsoft Windows XP / Microsoft Windows Server 2003 / Microsoft Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s
)
Ports
Purpose
Service
SIPLACE OIS Monitoring Service
(Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Monitoring Service\
MonitoringService.exe
Monitorin
gService
Inbound
HTTP
51001
SSI.Messages
Service
SIPLACE OIS OIS Server (Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Monitoring Service\
OisServer.exe
OisServer
Inbound
HTTP
52052
Ois-MonitoringConverter
Application
SIPLACE OIS Client (DCOM)
%ProgramFiles%\
Ois\
OisClient.exe
N/A
Inbound
DCOM
DCOM
Range
Data Exchange with
Data process
Application
SIPLACE OIS Buffer (DCOM)
%Program Files%\
Ois\
OisData.exe
N/A
Inbound
Outbound
DCOM
DCOM
Range
Buffer process for
OisClient
5.1.27 Line Shortage Tracker / LED Pairing Controller
The following rules are especially for Microsoft Windows XP / Microsoft Windows Server 2003 / Microsoft Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s
)
Ports
Purpose
Service
SIPLACE LST Pairing Controller
(Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing Controller\
LedPairingController.exe
Inbound
TCP
TCP
HTTP
1666
1667
33334
LstControlPort
LstDiagnosisPort
BGK:BoardNotifications
Support Media V1.15 10/2013 Edition
46
SetupCenter.exe
XP/W2003/W7
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s
)
Ports
Purpose
Application
SIPLACE LST Viewer (Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing Controller\
LedPairingControllerViewer.exe
Inbound
TCP
1655
LstViewerPort
Application
SIPLACE LST Tool (Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing Controller\
LedPairingTray.exe
Inbound
TCP
1655
DecisionRequestLaunch
er
5.1.28 SIPLACE Explorer
Component
Name Of The Rule
Path
Service
Name
Direction
Protocol(s
)
Ports
Purpose
Service
SIPLACE Tomcat.exe
%ProgramFiles%\
Apache Software Foundation\Tomcat
5.5\bin\tomcat5.exe
(as defined by user during setup via
SupportMedia)
Inbound
HTTP
8080
(as defined by
user during
setup via
SupportMedia
)
Access to SIPLACE
Explorer Websites
Service
SIPLACE SiEx.exe
%ProgramFiles%\
SIPLACE Explorer\SiEx.exe
Inbound
TCP
1099, 1100,
1101,
1102
Access to SIPLACE
Explorer runtime via
Java RMI.
Application
SIPLACE Tomcatw.exe
%ProgramFiles%\
Apache Software Foundation\Tomcat
5.5\bin\tomcat5w.exe
(as defined by user during setup via
SupportMedia)
Inbound
TCP
1099, 1100,
1101,
1102
Java RMI.
Application
SIPLACE javaw.exe
%ProgramFiles%\
Java\jre6\bin\javaw.exe
Inbound
TCP
1099, 1100,
1101,
1102
Java RMI.
Support Media V1.15 10/2013 Edition
47
5.2 Configuration of DCOM
MSDN article “How to configure RPC dynamic port allocation to work with firewalls” describes how
to configure RPC using certain ports. See URL for details:
http://support.microsoft.com/kb/154596/EN-US
Please consult the MSDN article “Cannot set a fixed endpoint for a COM+ application” to see that
COM+ cannot be configured like DCOM. See URL for details:
http://support.microsoft.com/default.aspx?scid=kb;en-us;Q312960
