Support Media V1.15 10/2013 Edition
42
Component
Rule Name
Path
Service Name
Direction
Protoc
ol
(UDP/T
CP)
Port
Purpose
SIPLACE OIB
Calendar
Service
Service
SIPLACE OIB DS Service
<OIB_INSTALLDIR>Core\Display
Service\ASM.AS.OIB.DisplayService.Host.exe
OibDisplayService
Inbound/Outbound
ANY
ANY
Allow access to
the SIPLACE
OIB Display
Service
Service
SIPLACE OIB MON Service
<OIB_INSTALLDIR>Monitoring
Adapter\ASM.AS.OIB.Monitoring.Host.exe
OibMonitoringService
Inbound/Outbound
ANY
1477
Allow access to
the SIPLACE
OIB Monitoring
Service
Service
SIPLACE OIB SC Service
<OIB_INSTALLDIR>Setup Center
Adapter\ASM.AS.OIB.SIPLACESetupCenter.Ho
st.exe
OibSetupCenterService
Inbound/Outbound
ANY
ANY
Allow access to
the SIPLACE
OIB Setup
Center Service
Service
SIPLACE OIB SPI Service
<OIB_INSTALLDIR>SIPLACE Pro
Adapters\SPI\ASM.AS.OIB.SIPLACEPro.Host.ex
e
OibSpiService
Inbound/Outbound
ANY
ANY
Allow access to
the SIPLACE
OIB SPI Service
Application
SIPLACE OIB SPI WP
Service
<OIB_INSTALLDIR>SIPLACE Pro
Adapters\SPI\ASM.AS.OIB.ServicePool.Worker
Process.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of SPI Worker
Process
Service
SIPLACE OIB OPT Service
<OIB_INSTALLDIR>SIPLACE Pro
Adapters\Optimizer\ASM.AS.OIB.SIPLACEPro.
Optimizer.Host.exe
OibOptimizerService
Inbound/Outbound
ANY
ANY
Allow access to
the SIPLACE
OIB Optimizer
Service
Application
SIPLACE OIB OPT WP
Service
<OIB_INSTALLDIR>SIPLACE Pro
Adapters\Optimizer\ASM.AS.OIB.ServicePool.W
orkerProcess.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of Optimizer
Worker Process
Service
SIPLACE OIB LC Service
<OIB_INSTALLDIR> Line
Control\ASM.AS.OIB.SIPLACEPro.LineControl.
Host.exe
OibLineControlService
Inbound/Outbound
ANY
ANY
Allow access to
the SIPLACE
OIB Line Control
Service
Application
SIPLACE OIB UM UI
<OIB_INSTALLDIR> Core\User
Management\ASM.AS.OIB.UserManagement.Us
erManager.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of User Manager
UI
Application
SIPLACE OIB FC UI
<OIB_INSTALLDIR> Core\Factory
Calendar\ASM.AS.OIB.FactoryCalendar.UI.exe
Inbound/Outbound
ANY
1429-
1528
Allow inbound
and outbound
communication
Support Media V1.15 10/2013 Edition
43
Component
Rule Name
Path
Service Name
Direction
Protoc
ol
(UDP/T
CP)
Port
Purpose
SIPLACE OIB
of Factory
Calendar UI
Application
SIPLACE OIB OM UI
<OM_INSTALLDIR>
SiplaceNet.OperationManager.Console.exe
Inbound/Outbound
ANY
1411-
1510,
1477-
1576
Allow inbound
and outbound
communication
of OIB Plugin for
the Operation
Manager
Application
SIPLACE OIB SOT
<OIB_INSTALLDIR> Tools\sot\sot.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of OIB SOT Tool
Application
SIPLACE OIB Test Box UI
<OIB_INSTALLDIR> Test
Box\ASM.AS.OIB.TestBox.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of Test Box UI
Application
SIPLACE OIB Test Box
Helper
<OIB_INSTALLDIR> Test
Box\ASM.AS.OIB.TestBoxHelper.exe
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of Test Box
Helper
Service
SIPLACE OIB MSDTC
<WINSYSDIR>MSDTC.exe
MSDTC
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of MSDTC
Service
OIB ClientAPI
Port
SIPLACE OIB HTTP
Endpoints (TCP In/Out)
N/A
Inbound/Outbound
TCP
1405
Allow access to
the OIB HTTP
endpoints
Port
SIPLACE OIB TCP Endpoints
(TCP In/Out)
N/A
Inbound/Outbound
TCP
1406
Allow access to
the OIB TCP
endpoints
Port
SIPLACE OIB TCP Endpoints
(TCP In/Out)
N/A
Inbound/Outbound
TCP
1477
Allow access to
the OIB TCP
endpoints for the
client status
callbacks
Port
SIPLACE OIB TCP SC
Callback (TCP In/Out)
N/A
Inbound/Outbound
TCP
65535
Allow access to
the OIB Setup
Center Proxy
Callback
endpoint
Support Media V1.15 10/2013 Edition
44
Component
Rule Name
Path
Service Name
Direction
Protoc
ol
(UDP/T
CP)
Port
Purpose
SIPLACE OIB
endpoints
Service
SIPLACE OIB MSDTC_API
<WINSYSDIR>MSDTC.exe
MSDTC
Inbound/Outbound
ANY
ANY
Allow inbound
and outbound
communication
of MSDTC
Service
Please note: The OIB Client API rules might need to be extended depending on the 3
rd
Party application configurations. These port numbers are
default ports that can be overridden by those applications.
