Support Media V1.15 10/2013 Edition
6
2 System Requirements
2.1 Supported Operating Systems and Database Variants
2.1.1 Server/Database Computer System
Server/Database Computer System
Software (required)
Preferred
Microsoft Windows Server 2012 (64 Bit)
Microsoft SQL Server 2008 R2 SP2 / Express Edition R2 SP2 (64 Bit)
Compatible Operating Systems
Microsoft Windows Server 2008 R2 SP1 (64 Bit)
Microsoft Windows Server 2008 SP2 (32 and 64 Bit)
Microsoft Windows Server 2003 R2 (32 and 64 Bit)
Microsoft Windows Server 2003 SP2 (32 and 64 Bit)
Compatible Databases
Microsoft SQL Server 2012 SP 1 / Express Edition (32 and 64 Bit)
Microsoft SQL Server 2008 R2 SP2 / Express Edition R2 SP2 (32 Bit)
Microsoft SQL Server 2008 SP3 / Express Edition SP3 (32 and 64 Bit)
Microsoft SQL Server 2005 SP4 / Express Edition SP4 (32 and 64 Bit)
Required
Microsoft .NET Framework 4.0
Hardware (recommended)
e.g. 2x Intel E5520 2.26 GHz 8MB
4096 MB RAM
HDD SATA II 500GB
Optional backup drive (e.g. DVD, DAT)
21“ monitor (19” monitor at least)
Optional: Uninterruptible power supply
NOTICE
Limitations and requirements for Microsoft SQL server
Microsoft SQL Server Express Edition is a scaled down, free edition of
Microsoft SQL server, which includes the core database engine. While there
are no limitations on the number of databases or users supported, it is limited
to using one processor, 1 GB memory and 4 GB database files (10 GB
database files from Microsoft SQL Server Express 2008 R2). These
limitations may impact the system performance).
64 bit Microsoft SQL Server editions require 64 bit operating systems.
A mixed operation of different Microsoft SQL server versions (2005 / 2008 /
2012) is not supported.
Support Media V1.15 10/2013 Edition
7
2.1.2 Client Computer System
Client Computer System
Software (required)
Preferred
Microsoft Windows 8 (64 Bit)
Compatible
Microsoft Windows 8 (32 Bit)
Microsoft Windows 7 SP1 (32 and 64 Bit)
Microsoft Windows XP SP3 (32 Bit)
Microsoft Windows Vista SP2 (32 and 64 Bit)
Required
Microsoft .NET Framework 4.0
Hardware (recommended)
e. g. 1x Core 2 Duo E8500
4096 MB RAM
HDD SATA II 250GB
21" monitor (19" at least) with a screen resolution of at least 1024 x 1280 pixel (small fonts)
Powerful graphics board with 256 MB RAM
2.2 Products of Release 60 (R60)
Product
Release 60
SIPLACE Station Software
707
SIPLACE Pro
11.1
SIPLACE OIS/SIS
11.0
SIPLACE Explorer
2.11
SIPLACE EDM
2.2
SIPLACE Setup Center
6.0
SIPLACE Traceability
3.6
SIPLACE Board Gate Keeper
1.2
SIPLACE OIB
3.2
SIPLACE LED Pairing Controller
2.0
SIPLACE License Manager
2.3 SP 2
SIPLACE Support Media
1.15
Support Media V1.15 10/2013 Edition
8
3 Compatibility
SIPLACE License Manager 2.3 SP2
SIPLACE Pro 11.1 Client
SIPLACE Pro 11.1 Server
SIPLACE EDM 2.2
SIPLACE OIS/SIS 11.0 Server
SIPLACE OIS/SIS 11.0 Client
SIPLACE Explorer 2.11
SIPLACE Setup Center 6.0 Server
SIPLACE Setup Center 6.0 Client
SIPLACE Traceability Monitor 3.6
SIPLACE Traceability Service 3.6
SIPLACE OIB 3.2 Infrastructure - Adapter
SIPLACE OIB 3.2 Infrastructure - Core Client
SIPLACE OIB 3.2 Infrastructure - Core Server
SIPLACE OIB 3.2 Infrastructure - Client API
SIPLACE Performance Monitoring 1.2 SP1 WebService
SIPLACE Performance Monitoring 1.2 SP1 Business
SIPLACE Performance Monitoring 1.2 SP1 Web GUI
SIPLACE Line Monitor 2.0 SP2 Server
SIPLACE Line Monitor 2.0 SP2 GUI
SIPLACE LED Pairing Controller 1.0 SP1
SIPLACE BoardGateKeeper 1.2
SIPLACE FM 2.2 SP1 Server
SIPLACE FM 2.2 SP1 Maintenance Server
SIPLACE FM 2.2 SP1 Client
SIPLACE FM 2.2 SP1 Line Console
SQL 2005 Express SP 4 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2005 SP 4 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2005 Express SP 4 x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2005 SP 4 x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2008 Express SP 3 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2008 SP 3 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2008 Express SP 3 x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2008 SP 3 x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2008R2 SP 1 Express n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2008R2 SP 1 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2008R2 SP 1 Express x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL Server 2008R2 SP 1 x64 n n x x x n x x n n x n n x n n x n n n n n x n n n
SQL 2008R2 SP 2 Express n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL Server 2008R2 SP 2 n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL 2008R2 SP 2 Express x64 n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL Server 2008R2 SP 2 x64 n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL 2012 SP 1 CU2 Express n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL Server 2012 SP 1 CU2 n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL 2012 SP 1 CU2 Express x64 n n x x x n x x n n x n n x n n - n n n n n - n n n
SQL Server 2012 SP 1 CU2 x64 n n x x x n x x n n x n n x n n - n n n n n - n n n
Windows XP SP 3 x86 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows XP SP 3 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Vista SP 2 x86 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Vista SP 2 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows 7 SP 1 x86 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows 7 SP 1 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows 8 x86 x x x x x x x x x x x x x x x x x x x x - x x x x x
Windows 8 x64 x x x x x x x x x x x x x x x x x x x x - x x x x x
Windows Server 2003 SP 2 x86 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Server 2003 SP 2 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Server 2008 SP 2 x86 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Server 2008 SP 2 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Server 2008 R2 SP 1 x64 x x x x x x x x x x x x x x x x x x x x x x x x x x
Windows Server 2012 x64 x x x x x x x x x x x x x x x x x x x x - x x x x x
Microsoft .Net Framework 3.5 Service Pack 1 x n n n x x n n n n n n n n n x x x x x n n n n n n
Microsoft .Net Framework 4.0 x x x x x x x x x n n x x x x x x x n n x x x x x x
Microsoft Internet Explorer 6 SP 1 n n n n n n x n n x x n n n n n n n n n n n n n n n
Sun JRE 1.6.0.43 n n n n n n x n n n n n n n n n n n n n n n n n n n
Tomcat 5.5.36 n n n n n n x n n n n n n n n n n n n n n n n n n n
n not needed (nicht benötigt)
x needed and supported (benötigt und unterstützt)
- needed but not supported (benötigt aber nicht unterstützt)
Figure 3-1: Compatibility of interoperable products
