00197214_IM_SupportMediaV1.15_EN.pdf - 第18页

Support Media V1.15 10/2013 Edition 18 ► On the computer with web - access, execute the S UPPORT_MEDIA_DOW NLOAD.EXE tool and select the appro priate download list using the option Fi le – Open Siplace Prer equi site Fil…

Support Media V1.15 10/2013 Edition

NOTICE

Default Download List location and naming

The default location for the Download List is

<MyDocumentsFolder>\PrerequisiteAnalyzer_ExternalDownloadList_<Computer

Name>.xml.

Since this list contains information specific to the computer, the name of the

download list contains the computer name for which it was created. This will help

you identifying it.

After you defined the location of the Download List, the Download List and the Support Media

Download Tool (“SUPPORT_MEDIA_DOWNLOAD.EXE”) will be saved to the specified location

and you will see a new Windows Explorer window appearing with the Download List selected, to

simplify finding the files created.

After that, the following message will be displayed.

Figure 4-6: Export finished message of Analyzer

► Click the Yes button if you want to close Analyzer later until you downloaded all files on the

other computer.

► Click the No button to step back to the previous options dialog, allowing you to select an

alternative Additional Software Search Folder containing all missing packages.

NOTICE

Complete download not always possible

As with the Download online option, there might be cases where software

packages are missing which can’t be downloaded automatically.

You will get an appropriate warning message, depending on your situation (e.g.

all missing software packages not downloadable, only a part of missing

Packages not downloadable).

Please use the Download and install manually option if you encounter this

problem. It will show you alternative hints and links on how to get/install the

missing Packages.

► Transfer the files to another computer with access to the Internet (e.g. using an USB drive).

Support Media V1.15 10/2013 Edition

► On the computer with web- access, execute the SUPPORT_MEDIA_DOWNLOAD.EXE tool

and select the appropriate download list using the option File – Open Siplace Prerequisite File.

► After that, the Download Tool will ask for a folder to store downloads. Select an appropriate

location.

NOTICE

Subfolder for download structure required

Prerequisite Analyzer only detects downloaded files, if the relative directory

structure to all Tools and Updates remains consistent. To ensure this, use a new

custom subfolder to store all download content. When transferring to the offline

computer, only this folder with all content needs to be copied.

► Click the Start button to initiate the download.

► After you completed the download of all packages successfully, close the Download Tool.

Transfer the contents of the download folder back to the computer you tried to prepare:

► On the computer you tried to prepare, start Prerequisite Analyzer and when asked, click the

option to select a local Additional Software Search folder.

► After you specified the search folder, click the button Copy offline files to Search Folder.

The following window appears.

Figure 4-7: Source folder selection dialog for copying download files back to local Search Folder

► Inside the Browse For Folder window, ensure that you have a valid connection to the location

of your download files (e.g. USB drive, network path).

Support Media V1.15 10/2013 Edition

NOTICE

Windows Vista or newer: User Account Control complicates accessing

network drives in Prerequisite Analyzer

Although the dialog supports accessing network drives, you may have problems

accessing network drives you mapped in Windows Explorer within Prerequisite

Analyzer because of Windows distinguishing between mapped drives during

normal user sessions and admin sessions.

► To access the network drive you mapped during a user session, right- click

on “My Network Places” inside the window, choose “map network drive” and

re- map the network drive inside the session of Prerequisite Analyzer.

► Select the appropriate location or enter the path to the location of your download files as shown

in the picture above.

► Click OK to continue.

Prerequisite Analyzer will now copy the downloaded files from the offline folder to the local

Software Search folder you specified before.

The window will look like this:

Figure 4-8: Prerequisite Analyzer copying files downloaded for offline use to local Search Folder

After the files have been copied, Prerequisite Analyzer will restart checking the Additional Software

Search Folder for needed files. If all required files have been found, you can continue.

4.4.4 Download and install manually option

After you selected the Download and install manually option, Prerequisite Analyzer will show you a

list of missing software packages as shown in the following picture.
