Support Media V1.15 10/2013 Edition
38
The following rules are appropriate with Microsoft Windows Vista and newer:
VtsAdapter.exe
Vista+ Rules
Rule Name
Path
Service
Name
Direction
Protocol
(UDP/TCP)
Port
Purpose
Application
SIPLACE Vision Teach Station (TCP
In)
%Program Files%\SIPLACE\SIPLACE
Pro\VtsAdapter.exe
N/A
Inbound
TCP
47310 -
47340
Allow TCP inbound
communication of
VtsAdapter
Application
SIPLACE Vision Teach Station (UDP
In)
%Program Files%\SIPLACE\SIPLACE
Pro\VtsAdapter.exe
N/A
Inbound
UDP
47310 -
47340
Allow UDP inbound
communication of
VtsAdapter
5.1.21 SIPLACE Pro Line Control
The following rules are especially for Microsoft Windows XP / Microsoft Windows Server 2003:
VtsAdapter.exe
XP/W2003 Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Line Control Dispatcher
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication of
LCDSVR.exe
Application
SIPLACE Line Control
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication of
LCSVR.exe
The following rules are appropriate with Microsoft Windows Vista and newer:
SIPLACE Pro
Vista+ Rules
Name Of The Rule
Application
SIPLACE Line Control (SOAP HTTP
Out)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t
filter
servicena
me –
doesn’t
work>
Outbound
TCP(HTT
P)
49001
Allow access to the
Station via HTTP
protocol
Application
SIPLACE Line Control (SOAP TCP
Out)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t
filter
servicena
me –
doesn’t
work>
Outbound
TCP
49002
Allow access to the
Station via TCP protocol
Application
SIPLACE Line Control (SOAP HTTP
%Program Files%\SIPLACE\SIPLACE
<Don’t
Inbound
TCP(HTT
49003
Allow access to the Line
Support Media V1.15 10/2013 Edition
39
SIPLACE Pro
Vista+ Rules
Name Of The Rule
In)
Pro\LCDSVR.exe
filter
servicena
me –
doesn’t
work>
P)
Control Server via HTTP
protocol
Application
SIPLACE Line Control (SOAP TCP
In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
<Don’t
filter
servicena
me –
doesn’t
work>
Inbound
TCP
49004
Allow access to the Line
Control Server via TCP
protocol
Application
SIPLACE Line Control (SOAP HTTP
Out to Setup Center)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t
filter
servicena
me –
doesn’t
work>
Outbound
HTTP
49041
Allow access to the
Setup Center via HTTP
protocol
net use
SIPLACE Line Control (net use)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
N/A
Outbound
NetBios
Protocol
139 / 445
Used to write Files onto
some Stations via
Network Share
Note: this rule is not
required – we use the
built- in File and Printer
Sharing rules instead
COM +
Application
SIPLACE Line Control (DCOM In)
%system32%\system32\dllhost.exe
(for %Program
Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 32
Bit host system
COM +
Application
SIPLACE Line Control* (DCOM In)
%system32%\SysWOW64\dllhost.exe
(for %Program
Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 64
Bit host system
COM +
Application
SIPLACE Line Control Server (RPC
In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control Server
COM +
Application
SIPLACE Line Control Dispatcher
(RPC In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control Dispatcher
You can freely configure network shares in the Line Control GUI Configuration (SIPLACE OS and Recipe Analyzer), which will be used by Line Control.
Support Media V1.15 10/2013 Edition
40
5.1.22 SetupCenter (SetupCenter.exe and SetupCenterServer.Service.exe)
The following rules are especially for Microsoft Windows XP / Microsoft Windows Server 2003 / Microsoft Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s
)
Ports
Purpose
Service
SIPLACE Setup Center Server
%ProgramFiles%\
SIPLACE\
SetupCenterService\
SetupCenterServer.Service.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication to
SetupCenterServer.Ser
vice.exe
Application
SIPLACE Setup Center
%ProgramFiles%\
SIPLACE\
SetupCenter\SetupCenter.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication to
SetupCenter.exe
5.1.23 Resources used by SIPLACE License manager application
The following rules are especially for Microsoft Windows XP / Microsoft Windows Server 2003:
SIPLACE Pro
Server
XP/W2003 Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE License Manager Host
%Program Files%\SIPLACE\SIPLACE
Licensemanager2\
Asm.As.License.Host.exe
N/A
Inbound
Any
All
Allow access to License
Host
The following rules are appropriate with Microsoft Windows Vista and newer:
SIPLACE Pro
Name oft he Rule
Application
SIPLACE License Manager Server
(SOAP In)
%Program Files%\SIPLACE\SIPLACE
Licensemanager2\
Asm.As.License.Host.exe
N/A
Inbound
TCP
1410
Allow access to the
SIPLACE
LicenseManager Server
via HTTP protocol
