Support Media V1.15 10/2013 Edition 16 Figure 4-4: Screen shot of Supp ort Media Do wnload tool NOTICE Complete do wnload not a lways pos sible Depending on the products you selec ted, your operatin g system and its conf…
Support Media V1.15 10/2013 Edition
15
Figure 4-3: Unavailable Installation Packages – Additional Software Search Folder defined, but not all required software
packages found
► Click the button Download online to initiate the download of missing software packages on this
computer directly
► Click the button Download offline if you don’t have web- access from your computer and want
to download the missing packages using another computer with web-access.
► Click the button Copy offline to Search Folder if you already downloaded all needed files on
another computer and now want to copy the files back to this computer. This option also allows
copying files from network drives to the local computer.
► Click the button Download and install manually to show the list of missing software packages
together with information and links for manual download and installation.
► Click the Specify Search Folder button to select a different (local) folder to search for missing
software packages.
4.4.2 Download Online option
After you selected the Download Online option the Support Media Download Tool will be used to
download missing required software packages to the Additional Software Search Folder you
defined before.
NOTICE
Download Tool requires .Net Framework 3.5 SP 1
To use the Download Tool, .Net Framework 3.5 SP 1 is required. Analyzer will
detect, if .Net Framework is missing and asks you to install it using the
appropriate Analyzer Profile from the profile group SIPLACE Net.
If you get this message, step back to the Product Selection page and select the
appropriate profile in SIPLACE Net\.Net Framework stand- alone setups only
(deselect previously selected profiles) to install .Net Framework 3.5 SP 1.
The following picture shows you an example.
Support Media V1.15 10/2013 Edition
16
Figure 4-4: Screenshot of Support Media Download tool
NOTICE
Complete download not always possible
Depending on the products you selected, your operating system and its
configuration, the availability of web-based links, etc. there might be software
packages missing, which can’t be downloaded automatically.
You will get an appropriate warning message, depending on your situation (e.g.
all missing software packages are not downloadable, only a part of missing
packages are not downloadable).
Please use the Download and install manually option if you encounter this
problem. It will show you alternative hints and links on how to get/install the
missing packages.
When the download of missing software packages completed successfully and no other packages
are missing, the Install button will be visible and the Analyzer will allow continuing automatic
preparation of your computer.
4.4.3 Download Offline option
After you selected the Download Offline option, Analyzer will ask for the location to store the
Download List as shown in the following picture.
Figure 4-5: Analyzer asking for the location to store the Download List
Support Media V1.15 10/2013 Edition
17
NOTICE
Default Download List location and naming
The default location for the Download List is
<MyDocumentsFolder>\PrerequisiteAnalyzer_ExternalDownloadList_<Computer
Name>.xml.
Since this list contains information specific to the computer, the name of the
download list contains the computer name for which it was created. This will help
you identifying it.
After you defined the location of the Download List, the Download List and the Support Media
Download Tool (“SUPPORT_MEDIA_DOWNLOAD.EXE”) will be saved to the specified location
and you will see a new Windows Explorer window appearing with the Download List selected, to
simplify finding the files created.
After that, the following message will be displayed.
Figure 4-6: Export finished message of Analyzer
► Click the Yes button if you want to close Analyzer later until you downloaded all files on the
other computer.
► Click the No button to step back to the previous options dialog, allowing you to select an
alternative Additional Software Search Folder containing all missing packages.
NOTICE
Complete download not always possible
As with the Download online option, there might be cases where software
packages are missing which can’t be downloaded automatically.
You will get an appropriate warning message, depending on your situation (e.g.
all missing software packages not downloadable, only a part of missing
Packages not downloadable).
Please use the Download and install manually option if you encounter this
problem. It will show you alternative hints and links on how to get/install the
missing Packages.
► Transfer the files to another computer with access to the Internet (e.g. using an USB drive).
