4.5.3 RIGHT DIS TRIBUTION MODULE No. Item Code No. Spe cification Description Type Q’TY Remark 1 V085- 520001 -A CABLE DUCT 1 P art 1 2 V085- 520003 -A CABLE DUCT COVER 1 Part 1 3 V085- 520004 -A CABLE DUCT COVER 2 Part …
4.5.3 RIGHT DISTRIBUTION MODULE
1
2
3
4
5
6
7
109
4.5.3 RIGHT DISTRIBUTION MODULE
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-520001-A CABLE DUCT 1 Part 1
2 V085-520003-A CABLE DUCT COVER 1 Part 1
3 V085-520004-A CABLE DUCT COVER 2 Part 1
4 602911-000044 HSP0130-2B-18R-481L-37 CAFLUX Part 1
5 602911-000043 HSP0130-2B-18R-559L-43 CAFLUX Part 1
6 A010-D51005 FITTING BLOCK Assembly 1 4.5.3.1
7 554011-000005 PM-Y44 PHOTO SENSOR Part 3
110
5 COVER (EXTERIOR)
1
3
4
5
2
6
7
8
111
