4. 1. MOTION CONTROL BLOCK DIAGRAM
14
No.
Item Code No.
Specification
Description
Type
Q’TY
Remark
1
501013-000017
MCB-A4(V4.3)
4-Axis Motion Control
Electric
1
I/O Motion Control Board
2
501013-000020
MCB-JC-2B,2C
Command Cable(2M-B,C)
Cable
2
Motion Cable
3
501013-000019
MCB-JB V6.0 R
Junction Interface Board
Electric
1
Motion I/F Board
4
555016-000012
RS1A01AA
SERVO DIRIVER
Electric
2
X, Z-Axis Servo AMP
5
555016-000015
RS1L03AA
SERVO DIRIVER
Electric
1
Y-Axis Servo AMP
6
555013-000013
R2AA06020FXH00(200W)
SERVO MOTOR
Electric
1
X-Axis Servo Motor
7
555013-000014
R2AA08075FXH00(750W)
SERVO MOTOR
Electric
1
Y-Axis Servo Motor
8
555013-000012
R2AA04010FXH00(100W)
SERVO MOTOR
Electric
1
Z-Axis Servo Motor
9
554011-000005
PM-Y44
PHOTO SENSOR (Limit Sensor)
Electric
6
10
E019-0241100
Servo Driver Main Power Cable
Cable
1
11
E019-0241200
Servo Driver Control Power Cable
Cable
1
12
E019-0241300
Limit Sensor 24V Power Cable
Cable
1
13
E019-0241400
Motion I/F 24V Power Cable
Cable
1
14
E019-0242100
Motion Board Command Cable
Cable
1
15
E019-0243100
X-Axis Servo Driver Command Cable
Cable
1
16
E019-0243200
Y-Axis Servo Driver Command Cable
Cable
1
17
E019-0243300
Z-Axis Servo Driver Command Cable
Cable
1
18
E019-0244100
Servo Motor Power Cable 1
Cable
1
19
E019-0244200
Servo Motor Power Cable 2
Cable
1
4. 2. MOTION CONTROL PART LIST
15
No.
Item Code No.
Specification
Description
Type
Q’TY
Remark
20
E019-0244300
Servo Motor Power Connector
Cable
1
21
E019-0246100
Rotary Encoder Cable 1
Cable
1
22
E019-0246200
Rotary Encoder Cable 2
Cable
1
23
E043-0246300
Rotary Encoder Connector
Cable
1
24
E043-0247100
Limit Sensor Cable 1
Cable
1
25
E043-0247200
Limit Sensor Cable 2
Cable
1
26
E043-0247300
Limit Sensor Connector
Cable
1
27
28
16
