KY8030-2XDL(2P) Part List (20120430).pdf - 第123页
1 5.4.1 MONIT OR HI NGE UNIT 2 3 4 5 6 7 9 8 123
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-920005-B RIGHT FRONT COVER Part 1
2 V085-910005-A HANDLE ADAPTER Part 4
3 609021-000011 KA-1251-14 HANDLE Part 2
4 504013-000001 KO-GX280SMT 17” LCD MONITOR Part 1
5 V085-920014-B KEYBOARD PLATE Part 1
6 504015-000002 GP-K7000 BLACK KEYBOARD Part 1
7 V085-920015-A USB BKT Part 1
8 609027-000008 KC-312-2-1-B BALL CATCH Part 2
9 V085-920017-A EM KEY BKT Part 1
10 551614-000001 AZ 17/170-B1 INTERLOCK S/W KEY Part 1
11 M090-900011 MONITOR HINGE UNIT Assembly 1 5.4.1
5.4 FRONT UPPER COVER UNIT
122
1
5.4.1 MONITOR HINGE UNIT
2
3
4
5
6
7
9
8
123
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-920013-B ANGLE PLATE Part 1
2 M090-910010-A HINGE SPACER Part 12
3 M090-910009-A HINGE BLOCK 02 Part 6
4 M090-910008-A HINGE BLOCK 01 Part 6
5 V085-910001-B HINGE BASE BLOCK Part 2
6 V085-910009-A URETHAN Part 2
7 V085-910007-A DOOR STOPPER Part 1
8 V085-920022-B ANGLE PLATE COVER Part 1
9 V085-910010-A HINGE SHAFT Part 6
5.4.1 MONITOR HINGE UNIT
124
