KY8030-2XDL(2P) Part List (20120430).pdf - 第98页
No. Item Code No. Specification Description Type Q’TY Remark 1 703012 - 000002 SS5YJ3- 32 -3- M5 MANIFOLD Part 1 2 703011 - 000003 SYJ324-5MZ SOL. V /V Part 1 3 703011 - 000002 SYJ3230-5MZ SOL. V/V Part 2 4 709016 - 0000…
4.5.1.4 MANIFOLD ASSEMBLY
97
5
6
7
8
1
2
3
4
No. Item Code No. Specification Description Type Q’TY Remark
1 703012-000002 SS5YJ3-32-3-M5 MANIFOLD Part 1
2 703011-000003 SYJ324-5MZ SOL. V/V Part 1
3 703011-000002 SYJ3230-5MZ SOL. V/V Part 2
4 709016-000001 1/8” BOLT Part 2
5 706012-000006 KJS04-M5 FITTING Part 5
6 706012-000008 M-5P FITTING Part 1
7 706012-000004 KQ2V08-01S FITTING Part 1
8 705018-000001 AN103-01 SILENCER Part 1
4.5.1.4 MANIFOLD ASSEMBLY
98
4.5.1.5 MOTOR UNIT 1
99
1
2
3
