KY8030-2XDL(2P) Part List (20120430).pdf - 第77页
4.3.1 UP/D OWN RAIL 3 1 2 3 4 5 7 6 8 77
No. Item Code No. Specification Description Type Q’TY Remark
8 602415-000019 SMALL 3D FRANGE ROLLER ROLLER Part 10
9 602415-000016 ESD D FLANGE BELT ROLLER ROLLER Part 4
10 602013-000038 ESD-RING-BELT-2100-DL1 RING BELT Part 1
11 A010-D53004 UP/DOWN RAIL 3 Assembly 1 4.3.1
12 A010-D53005 TESIONER 2 Assembly 1 4.2.3
13 V085-520011-A LANE 2 CAFLUX BKT Part 1
14 A010-D52011-A CONNECTER BKT 1 Part 1
15 A010-D52015-A SENSOR DOG 4 Part 1
16 554011-000003 PM-K44 PHOTO SENSOR Part 1
17 554011-000005 PM-Y44 PHOTO SENSOR Part 1
18 A010-520016-A SMALL BELT GUIDE Part 2
19 A010-D51021-A LM GUIDE BLOCK Part 2
4.3 THIRD MOVINF RAIL (REAR)
76
4.3.1 UP/DOWN RAIL 3
1
2
3
4
5
7
6
8
77
No. Item Code No. Specification Description Type Q’TY Remark
1 A010-D51007-A RING BELT RAIL Part 1
2 A010-D51016-A INLET CYLINDER BLOCK Part 1
3 609037-000007 URETHANE STOPPER STOPPER Part 2
4 A010-D51017-A INLET CYLINDER JOINT Part 1
5 A010-D51018-A INLET CYLINDER HOUSING Part 1
6 706012-000003 M-5AU-4 FITTING Part 2
7 701011-000014 CQ2A-16-10D CYLINDER Part 1
8 A010-D52013-A SENSOR DOG 2 Part 1
4.2.1 UP/DOWN RAIL 3
78
