4.1.4 HEIGHT GUIDE No. Item Code No. Spe cification Description Type Q’TY Remark 1 A010- 510029 -B HEIGHT GUIDE Part 1 2 A010- 510007 -B HEIGHT JOINT BKT Part 1 3 602711 - 000014 UH8- 10 COMPRESSION SPRING Part 1 4 V080-…
4.1.4 HEIGHT GUIDE
1
2
3
4
5
6
7
49
4.1.4 HEIGHT GUIDE
No. Item Code No. Specification Description Type Q’TY Remark
1 A010-510029-B HEIGHT GUIDE Part 1
2 A010-510007-B HEIGHT JOINT BKT Part 1
3 602711-000014 UH8-10 COMPRESSION SPRING Part 1
4 V080-510037-A UP DOWN CYLINDER JOINT Part 1
5 A010-510006-B HEIGHT CYLINDER BKT Part 1
6 701011-000004 CJPB15-5 CYLINDER Part 1
7 706011-000003 AS1211F-M5-04 SPEED CONTROL Part 1
50
4.1.5 TESIONER
1
2
3
51
