Scope of Delivery
Languages
40 SIPLACE Setup Center 6.3 SP2
System Requirements
Computers
SIPLACE Setup Center 6.3 SP2 41
4
4 System Requirements
System Requirements
4.1
4.1 Computers
Computers
4.2
4.2 Resource Requirements
Resource Requirements
NOTICE
NTFS partitioning
SIPLACE Setup Center requires a NTFS partitioning for installation. FAT or FAT32 file systems
are not supported.
Installation of SIPLACE Setup Center onto a FAT partitioning will be interrupted by the setup
program.
NOTICE
Licence Manager 2.3 (SP2)
SIPLACE Setup Center 6.3 requires license manager 2.3 (SP2) for operation.
Depending on the selected function, one or more licenses are required for operating Setup
Center.
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE Sup-
port Media 1.16, item no [00197214-xx].
NOTICE
The size of the database server depends on the amount of the packaging unit data.
► Large data amounts require a higher server performance.
Hard Disk Main Memory
▪ Windows approx. 2500 MB
▪ Program files approx. 90 MB
▪ Database = number of recorded batches x 1
KB
▪ Windows approx. 200 MB
▪ SQL Server with Setup Center database ap-
prox. 150 MB
▪ Setup Center GUI approx. 100 MB
System Requirements
Supported Software
42 SIPLACE Setup Center 6.3 SP2
4.3
4.3 Supported Software
Supported Software
Programming system
SIPLACE Setup Center supports the following version in online and offline mode:
Station software
SIPLACE Setup Center supports the following station software versions:
Pre-Setup Unit for X- and SXTables
The pre-setup unit for X and SX tables (docking station) requires the following:
SIPLACE Pro Interface version SIPLACE Pro Desk version
5.0 SP1, 5.2, 6.0, 7.0,8.0, 9.2, 9.3 ,10.0, 10.1 or
11.x
5.0 SP1, 5.2, 6.0, 7.0, 8.0, 9.2 , 9.3, 10.0, 10.1 or
11.x
Forced setup verification Unforced setup verification
407.05 Hotfix 9
505.05 SP2 Hotfix 3
605.03 SP5
10x.x,
401.x, 402.x, 403.x, 406.x
407.05 Hotfix 9 (recommended)
408.x
501.x, 502.x, 503.x, 504.x
505.05 SP2 HF3 (recommended)
60x.x
703.xx or higher 70x.x
CAN-Bus PCI Karte X-Dockingstation SX-Dockingstation
Sontheim PCI CAN-driver
7.4.14.0. 0 or higher version (on
the product CD)
▪ Hardware 0.05
– BIOS-Firmware 02.00 or
higher version
– Application-Firmware
04.49 or higher version
(The firmware files are included
in the Stations software CD
706.01 or higher version).
▪ Hardware 0.06 respectively
0.08
– BIOS-Firmware 00. or
higher version
– Application-Firmware
01.C6 or higher version
OR
▪ Hardware 0.0A respectively
0.0C
– BIOS-Firmware 00.0D or
higher version
– Applikation-Firmware
01.C6 or higher version
(The firmware files are included
in the Stations software CD
706.01 or higher version).
