System Requirements
Supported Hardware
SIPLACE Setup Center 6.3 SP2 43
4.4
4.4 Supported Hardware
Supported Hardware
Supported barcode readers
▪ Datalogic DRAGON
TM
M101 (1D barcode scanner)
▪ Datalogic DRAGON
TM
M131 (1D barcode scanner)
▪ Datalogic PowerScan® M8300 (1D barcode scanner)
▪ Datalogic PowerScan® M8500 (2D barcode scanner)
▪ Datalogic PowerScan® BT8300 (1D barcode scanner)
▪ Datalogic PowerScan® M9500 (1D/2D barcode scanner)
▪ Symbol MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC75 Pocket PC (2D barcode scanner)
▪ Motorola MC3090 Pocket PC (1D barcode scanner or 2D barcode scanner)
▪ Motorola MC3190 Pocket PC (1D barcode scanner or 2D barcode scanner)
Supported barcode types
▪ Datalogic 1D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Code 16K; Code 49; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar
Stacked Omnidirectional
▪ Datalogic 2D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code; Post Codes; Australian Post; Brit-
ish Post; Canadian Post; China Post; Japanese Post; KIX Post; Korea Post; Planet Code; Post-
net; Royal Mail; Code (RM4SCC) ; EAN/JAN Composites; GS1 DataBar Composites; GS1
DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;
MacroPDF; MicroPDF417; PDF417; UPC A/E Composites
▪ Symbol / Motorola 2D barcode scanner:
– AusPostal, Aztec, Chinese_2of5, Codabar, Code11, Code128, Code39, Code93, Composite
AB, Composite C, D2of5, Datamatrix, DutschPostal, EAN13, EAN8, I2of5, JapPostal,
Korean_3of5, MaixiCode, MicroPDF, MicroQR, MSI, PDF417, QRCode, RSS14, RSSExp,
RSSLim TLC39, Trioptic39, UKPostal, UPCA, UPCE0, UPCE1, US4State, US4State_FICS, US-
Planet, USPostnet, WebCode
System Requirements
Supported Hardware
44 SIPLACE Setup Center 6.3 SP2
Supported machines
Supported feeder types
Machine
SIPLACE 80 F4, F4-6, S20; F5, F5 HM, S23
SIPLACE S25 HM, S27 HM, HS50, HS 50+, HS60, HF,
HF3
SIPLACE X2, X3, X4; D1, D2, D3, D4
SIPLACE CF, CS
SIPLACE X2, X3, X4, X4I
SIPLACE SX1, SX2, SX4, SX1 V2, SX2 V2
SIPLACE DX1, DX2, DX4
SIPLACE X4i S, X4 S, X3 S, X2 S
SIPLACE X4i S micron, X4 S micron
SIPLACE CA
NOTICE
Restrictions
Please note that the programming system SIPLACE Pro and the Setup Center station package
may limit this selection.
Feeder types
▪ All WPC types
▪ MTC 1 & 2
▪ All waffle-pack trays
▪ All standard SIPLACE tape feeders
▪ All standard SIPLACE linear feeders
▪ SIPLACE X adapters
▪ Special feeders (Road Runner, Road Runner
XLF, Multi Stick Feeder: IPTE MSF 60 AX and
IPTE MSF XL80 AX; LED Feeder TE und LED
Feeder HS)
▪ JTF-S and JTF-M Feeder
NOTICE
Restrictions
Please note that the programming system SIPLACE Pro and the hardware used may limit this
selection.
New Functions in Setup Center 6.3
Display of the Split Table
SIPLACE Setup Center 6.3 SP2 45
5
5 New Functions in Setup Center 6.3
New Functions in Setup Center 6.3
5.1
5.1 Display of the Split Table
Display of the Split Table
Purpose
Up to now, the table at a location could only be displayed as a complete table. The usage of a fixed table
(e.g. the fixed table in combination with a JTF-S/JTF-M Feeder) is now visible in the software.
Function
Example: SX12 with fixed table and JTF-S/M Feeder
5.2
5.2 Motorola Scanners MC3090 and MC3190
Motorola Scanners MC3090 and MC3190
Purpose
With version 6.3 and higher, Setup Center additionally supports the two Motorola scanners MC3090 and
MC3190.
5.3
5.3 User Interface of the Motorola Scanners in Chinese Language
User Interface of the Motorola Scanners in Chinese Language
Purpose
The user interface of Motorola scanners that are supported by ASM is available in Chinese language.
Function
If the scanner supports the display of Chinese characters (see prerequisite), the user interface at the
scanner is displayed in Chinese. The language of the Setup Center client must be set to Chinese.
NOTICE
Prerequisite
The language variant of the scanner operating system must be in Chinese Simplified. If this pre-
requisite is not met, the texts at the scanner are displayed in English.
