Restrictions Known Facts / Problems (General) 7.1.10 Scanning of the Brightn ess Class In formation Not Possible in Random Set - 56 SIPLACE Setup Center 6.3 SP2 7.1.10 7 . 1 . 1 0 S c a n n in g o f t h e B r ig h t n e …

Restrictions

7.1.1 Database Views Restriction

SIPLACE Setup Center 6.3 SP2 55

7 Restrictions

Restrictions

7.1

7.1 Restriction

Restriction

7.1.1

7.1.1 Database Views

Database Views

7.1.2

7.1.2 Windows Vista / 64 Bit Operating Systems

Windows Vista / 64 Bit Operating Systems

▪ The WLAN modules Scalance W788/W744 cannot be configured on 64 Bit operating systems with

the PST tool.

7.1.3

7.1.3 Splice Points

Splice Points

▪ When using splice sensors don't repair damaged packaging units with splice because repair splice

points cannot be distinguished from the normal splice points.

7.1.4

7.1.4 Set-Up Sheet

Set-Up Sheet

▪ Setup Center prints barcodes exclusively of the type Code-39. This type masters the following valid

characters: 0123456789 [space character] ABCDEFGHIJKLMNOPQRSTUVWXYZ-.$/+%. Other

characters are displayed as gap in the barcode and the barcode printout are not readable.

▪ When SIPLACE Pro 5.0 SP1 SP1 is used, the setup lists printed out do not contain graphics of the

components.

7.1.5

7.1.5 Recovery Placement

Recovery Placement

▪ Due to the restart of the machine, the value for the consumption of already placed components on

the boards that are not finished yet is lost.

7.1.6

7.1.6 X And SX Docking Station

X And SX Docking Station

▪ Before starting Setup Center all X docking stations connected via the CAN bus must be online.

Only then it is possible for Setup Center to recognize the type of the docking station correctly.

▪ In order to verify the tracks of a changeover table with 30 tracks, the feeders must first be placed

onto tracks 31 to 60 of a 60 track wide changeover table in the docking station and then be verified.

After that, the feeders must be replaced onto the 30 track wide changeover table.

7.1.7

7.1.7 Mat Label

Mat Label

▪ The barcode parts are invariably described with a fixed description in the Barcode Rules Editor. How-

ever, the definition of MAT labels can be copied and changed as required.

7.1.8

7.1.8 Offline Verification of Partial Setups

Offline Verification of Partial Setups

Setup Center does not support the following SIPLACE Pro functions for "Offline verification of partial set-

up".

▪ Combined PCB

▪ Virtual PCB stack

▪ Quadlane

7.1.9

7.1.9 Maximum Number of Stations in the Line

Maximum Number of Stations in the Line

Setup Center allows a maximum number of 9 stations in a line.

If there are more than 9 stations, this could cause errors during the scanning of control barcodes.

NOTICE

The data access via OIB interface is recommended.

Restrictions

Known Facts / Problems (General) 7.1.10 Scanning of the Brightness Class Information Not Possible in Random Set-

56 SIPLACE Setup Center 6.3 SP2

7.1.10

7.1.10 Scanning of the Brightness Class Information Not Possible in Random Setup Mode

Scanning of the Brightness Class Information Not Possible in Random Setup Mode

If the setup to be verified uses the Random Setup functions (Arbitrary track, or Arbitrary track and level),

the brightness class information cannot be scanned with the barcode scanner. This results in a constant

failure of the required brightness class check for a component.

If the packaging units have a unique ID and if the packaging unit data including the brightness class in-

formation are already present in the Setup Center database (e.g. after an import of XML data or through

a MES system), a successful check of the brightness class is possible.

7.2

7.2 Known Facts / Problems (General)

Known Facts / Problems (General)

7.2.1

7.2.1 Update Installation

Update Installation

▪ A backup copy is created during the installation. This backup copy can be used to recover the data-

base if a fallback to the old version should be necessary.

▪ We recommend that you reduce the database to a minimum before updating to a newer version of

Setup Center

(see user manual: Database Maintenance).

▪ When updating the installation at least 1.7 times the size of the Setup Center database must be avail-

able as free disk space.

▪ Depending on the size of the database and the hardware used, the database update can take up to

several hours.

▪ During the database upgrade the Setup Center GUI must not be started and no production must be

in progress.

▪ Up to Setup Center version 6.0, barcode labels were saved locally for each Setup Center installation.

With Setup Center version 6.3 and higher, the barcode labels are saved in the Setup Center data-

base. After the update installation from an older Setup Center version to Setup Center 6.3 and high-

er, check the sequence and the settings of the barcode labels.

7.2.2

7.2.2 Setup Verification

Setup Verification

▪ It is a requirement that feeders are not pulled out or switched during setup verification. To put it dif-

ferently, as long as setup verification takes place for a single track, the feeder and the corresponding

packaging units must remain in the same location.

▪ Urgent recommendation: when splicing a reel it must be verified immediately (refill mode). Otherwise

there is a danger of unverified components being placed when the pickup rates are extremely poor

and the threshold values are low. If no Splice sensors are installed the remaining quantity of a tape

running empty should be checked and corrected before splicing.

7.2.3

7.2.3 Partial Setup

Partial Setup

Setup verification for partial setups at S feeders behaves differently than at X feeders because S feeders

don't have a feeder ID.

7.2.4

7.2.4 Quantity Management

Quantity Management

▪ If the packaging unit without unique ID is taken from the feeder, the information about the remaining

filling level is lost or unclear. It is no longer possible to monitor the quantities on the reels. If the pack-

aging unit is configured anew, you will need to manually correct the quantity.

▪ If no packaging unit size is defined as barcode, the number of components as indicated in SIPLACE

Pro is used. Component shape quantity information from SIPLACE Pro will be ignored.

7.2.5

7.2.5 Feeders

Feeders

▪ Refilling of a tray in a WPC / MTC always causes setting up. That means that the preceding pack-

aging unit is torn down and the just scanned packaging unit is set up.

Restrictions

7.2.6 SIPLACE Pro Known Facts / Problems (General)

SIPLACE Setup Center 6.3 SP2 57

7.2.6

7.2.6 SIPLACE Pro

SIPLACE Pro

▪ Setup Center references objects in SIPLACE Pro by names and is therefore unable to find them

again, if the names are subsequently changed.

▪ Case-sensitive SIPLACE Pro object names are retained in Setup Center, but case-sensitivity is not

relevant.

▪ In general, Setup Center does not actively react to changes made in SIPLACE Pro. This means that

all actions like renaming, moving, changing objects are not tracked by Setup Center. After changes

have been made in SIPLACE Pro, Setup Center needs to reload the setups. In the case of online

verification, the setup needs to be transmitted to the line again via SIPLACE Line Control. In the case

of offline verification, it is sufficient to close and reopen the setup. Adding, deleting and changing a

barcode to a component is recognized. The renaming of lines in the line configuration is also recog-

nized.

7.2.7

7.2.7 Length of the Setup Names

Length of the Setup Names

▪ The length of setup names is limited to 20-50 characters for machines of the S, F, HS and HF series,

i.e. only the first 20 or 50 characters are looked at when there is a setup change.

7.2.8

7.2.8 Special Characters

Special Characters

▪ Do not use characters with the hexadecimal codes [00 - 19; D800 - DFFF; FFFE; FFFF] for barcodes,

as these cannot be transferred to the machines.

7.2.9

7.2.9 Docking Station

Docking Station

▪ If the Docking Station is switched off, Setup Center must be re-started, so that the Docking Station

and Setup Center can synchronize correctly. The start of the Docking Station can last up at a minute.

Setup Center must not be started beforehand.

▪ A CAN Bus PCI Card is necessary to connect the docking station. This card enables you to connect

a maximum of 8 docking stations. The card supports 2 CAN busses so that 4 docking stations can

be connected to each bus. A maximum of one CAN Bus PCI Card per computer is possible.

▪ If the CAN Bus is not properly terminated, problems may arise when trying to connect.

7.2.10

7.2.10 Manual Barcode Input

Manual Barcode Input

▪ When the barcode is entered manually, registration of user barcodes (via Barcode Wizard) is not

supported.

7.2.11

7.2.11 Multiple Instances Setup Center

Multiple Instances Setup Center

▪ Setup Center does not synchronize several running instances. The GUI is updated only when the

associated data is changed in the current instance of Setup Center. This happens most frequently if

for example one Setup Center instance is used in the pre-setup area and another one at the line.

The tables taken from offline to online are only updated in the Setup Center instance on the line.

▪ Offline setup data can be refreshed by closing and re-opening the offline setup verification.

Station software Max. length of setup names

407 20 characters exc. path

505 50 characters exc. path

From 605 and higher

From 703 and higher

255 characters inc. path

NOTICE

Do not use special characters

We recommend that you do not use special characters since it can cause errors.
