TRANSPORT RAILS MODULE
ADJUSTMENTS AND SETTINGS
16.18 Technical Reference Manual Chapter Issue 6 Oct 06
Rear Snugger
Plate Parallelism
1. Open the front printhead cover/shutter.
2. Slacken the two rear snugger plate securing screws.
3. Place a product board centrally between the snuggers.
4. In Diagnostics, select Rail System.
5. Select Select Module.
6. Select Toggle Board Clamp.
7. Select Run Diagnost, the edge of the rear snugger plate aligns with the
edge of the board.
8. Tighten the two rear snugger plate securing screws.
9. Remove the product board from the machine and exit from diagnostics.
Home Position Rail
Width Check
1. Ensure that board clamps are fitted and that the Board Clamp Setting
procedure (this section refers) has been carried out.
2. In Diagnostics select Rail System.
3. Select Select Module.
4. Select Home Rail Width.
5. Select Run Diagnost.
6. Select Adjust and set board width to 250mm.
7. Select Exit.
8. Select Drive Rail to Board Width.
9. Select Run Diagnost.
10. Open the front printhead cover/shutter.
Downstop Screws
Downstop Screws
Rear Snugger Plate Rear Snugger Plate Securing Screws
Plan View of Rail System
TRANSPORT RAILS MODULE
ADJUSTMENTS AND SETTINGS
Chapter Issue 6 Oct 06 Technical Reference Manual 16.19
11. Place a vernier gauge above the transport belts in the centre of the board
clamps and check that the vernier reads between 250.25mm ±0.10mm.
12. If the rail width is correct, go to Step 22.
13. Close the printhead cover/shutter and press the System button.
14. Select Set Rail Board Width Calibration.
15. Select Run Diagnost to open the Rail Width Offset window.
16. Use Incr. or Decr. to set the offset required to achieve the dimension in Step
11.
NOTE
Increasing the offset increases the dimension between the rear rail and the
home position therefore, decreasing the width between the front and rear
rails.
17. Select Move.
18. Open the front printhead cover/shutter and recheck the measurement.
250.25mm ±0.10mm
Rear Board Clamp
Plan View of Board Clamps
Transport Belts
Front Board Clamp
Plan View of Transport Rails (centre section)
Home Position
Rail Width
RAIL WIDTH OFFSET 0.00 mm
+/- 3.00mm
TRANSPORT RAILS MODULE
ADJUSTMENTS AND SETTINGS
16.20 Technical Reference Manual Chapter Issue 6 Oct 06
19. If the rail width is incorrect, close the printhead cover/shutter, press the
System button and repeat Steps 16 to 18.
20. If the rail width is correct, close the printhead cover/shutter, press the
System button and select Set.
21. Select Yes to save the information.
22. Using a suitable test board, with the rail width programmed to the board size,
select Cycle Board on Belts.
23. Select Run and ensure the board runs through the entire length of the rail
system for 10 complete cycles, without jamming or excessive clicking of the
board edges.
NOTE
If any jamming occurs investigate the position of the board/snugger clamps
before repeating the check.
