Brief Description Requirements and Restrictions for the CPP Place ment Head Reconfi guration Duration 50 Assembly Instructions / Montageanleitung Head Reconfiguratio n Kit CPP Requirements and Restrict ions for the CPP P…

Brief Description
Options for CPP Tools and Equipment Required
Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP 49
Tools and Equipment Required
2.2 Tools and Equipment Required
Designation Item No.
Torque wrench 03078400-xx (old version: 00376504-xx)
Extension with joint (170 x SK3) 03042635-xx
Extension straight (170 x SK3) 03043440-xx
Tool extension straight TX20 03073256-xx
Bit holder for TorqueVario screwdriver 03078706-xx
Depth measuring gauge 200 mm 03079617-xx
Pressure test device with measurement cable 00313523-xx
Conversion kit COT insert X 00378465-xx
Mapping Plate SX 560x460 Set
or
Alu Mapping Plate 560 x 460 D, SX1/2
03076118-xx
03076765-xx
Calibration tool version 3 CPP 03010565-xx
Calibration tool version SST23 C&P20 03034148-xx
Assembly Instructions Stationary Camera SX Series 00196608-xx
Assem Assembly Intructions SIPLACE SX 1/2 Noz
-
zle Changer
00196578-xx
Assembly Instructions Reject Bin SIPLACE SX Se
-
ries
00196615-xx
Assembly Instructions Stationary Camera Type 25
SIPLACE X Series, SX1/2, D3 and D1
00194554-xx
Service Manual SX1/2 00196496-xx

Brief Description
Requirements and Restrictions for the CPP Placement Head Reconfiguration Duration
50 Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP
Requirements and Restrictions for the CPP Placement Head
2.3 Requirements and Restrictions for the CPP Placement Head
▪ The camera type is added during the configuration query of the head reconfiguration kit. The C&P
component camera (type 29) 27x27 digital RK [03018637-xx] is the default.
– [03018637-xx] C&P component camera (type 29) 27x27 digital RK (default)
– [00119783-xx] CPP head camera (01005) (type 38)
▪ In a placement area with 2 gantries the CPP heads may only be installed on the same height. Thus,
both CPP heads have to be installed in either the high or the low position.
▪ If the CPP head is used together with a TwinHead in a placement area with 2 gantries, the CPP head
may only be installed in the high position.
▪ When using third party feeder modules pay particular attention on the crash danger.
▪ It is not possible to use a vacuum pump together with a CPP head. The head principle requires a
compressed air supply for the time being.
▪ During the placement of a PCB no nozzle change is executed with CPP heads (applies to old modes:
C&P, P&P and Mixed).
▪ In conjunction with a stationary camera the CPP head must always be installed in the high position
and the stationary camera in the low position.
▪ The CPP head can only be used with stationary cameras of function status -04 or higher.
▪ When using a CPP head no magazines of the C&P20A head are allowed on the nozzle changer.
This is monitored by the software.
Reconfiguration Duration
2.3.1 Reconfiguration Duration
The following reconfiguration durations per head can be expected:
Placement head Single-/Double conveyor Task
Disassembling CPP 20 min Without options such as nozzle changers, verify
component reject bin and stationary camera
Disassembling
C&P20A
20 min Without options such as nozzle changer, verify
component reject bin
Disassembling Twin
-
Head
30 min Verify Component reject bin
Assembling CPP 90 / 120 min With mapping and without options such as nozzle
changer, verify component reject bin and stationary
camera
Assembling C&P20A 90 / 120 min With mapping and without options such as nozzle
changer, query component reject bin
Assembling Twin
-
Head
90 / 120 min With mapping and without options such as nozzle
changer, verify component reject bin and stationary
camera

Brief Description
SIPLACE SX 1 Head Modularity SX 70x
Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP 51
Head Modularity SX 70x
2.4 Head Modularity SX 70x
The CPP head can either be installed in a high or a low position.
The following terms mean:
▪ Installation position low: CPP_L corresponds to a component height of 6 mm maximum.
▪ Installation position high: CPP_H corresponds to a component height of 11.5 mm maximum.
The following head configuration options are available:
SIPLACE SX 1
2.4.1 SIPLACE SX 1
Head configurations on the SIPLACE SX 1
SIPLACE SX 2
2.4.2 SIPLACE SX 2
Head configurations on the SIPLACE SX 2
Gantry 1 Default cameras Options
C&P20A STT 23 ----
CPP_H SST 29 Component camera SST 38
Stat. camera SST 33 (from FS 04 and in low installation posi
-
tion only)
CPP_L SST 29 Component camera SST38
TwinHead SST 33 Stat. camera SST 25 (location 1 only)
3D coplanarity module ST 37 (location 1 only)
Gantry 1 / Gantry 2 Default cameras Options
C&P20A / C&P20A STT 23 ----
CPP_H / CPP_H SST 29 Component camera SST 38
Stat. camera SST 33 possible on location 1 and
2 (from FS 04 and in low installation position on
-
ly)
CPP_L / CPP_L SST 29 Component camera SST38
CPP_H / TwinHead STT 29 (on gan
-
try 1)
Twin SST33 (on
gantry 2)
CPP:
Component camera SST 38
Stat. camera SST 33 (from FS 04 and in low in
-
stallation position only)
TwinHead:
Stat. camera SST 25 (location 1 only)
3D coplanarity module SST 37 (location 1 only)
TwinHead / TwinHead SST 33 Stat. camera SST 25 (location 1 only)
3D coplanarity module ST 37 (location 1 only)
