Fault Diagnostic for Closed Loop Servo Systems
The workcell uses a closed loop servo drive system. Shown below is a general fault diagnostic
table for this type of system.
Problem
Other Symptoms
Possible Cause
Corrective Action
When the axes
are homed, the
end effector
moves past the
home sensor
and hits the
hard stop
Home sensor is out of
position or too far away
from the homing tab
• Engage the “Emergency Stop”
button. Use your hand to move the
axis so the homing tab moves into
the home sensor, and the sensor is
on. Loosen the lock nut on the
sensor and adjust to .020” gap
Sensor cable is loose or not
connected
• Check the cable connections and
correct any loose connections
When the axes
are homed, the
Z-axis does not
move
SSR-1 is not ON
when the Z-axis
drive is enabled
The Z-axis brake does not
disengage when the drive
is enabled
• Examine the SSR-1 wiring, it
should be on when the Z- axis
drive is enabled
SSR-1 is ON when
the Z-axis drive is
enabled
The fuse for SSR-1 is blown
or damaged
• Examine the fuse with an OHM
meter and replace if necessary
Note: *If the SSR is on that does not mean it is functioning correctly. Use the test procedure for SSR5 in
the power check relay document to test SSR1 for correct operation.
The axis does
not have any
motion
Encoder works
according to the test
in Section 13.6
Axis speed/ acceleration is
set to zero
• Set the speed and acceleration to
a positive, non-zero value with the
SP and AC commands
The axis drive light is
RED
The axis drive is not
enabled
• Enable the drive with the SH
command
The axis cables are loose or
not connected
• Examine the cable connections
and repair any loose connections
The “Emergency Stop”
button is engaged
• Disengage the “Emergency Stop”
button
Hall Effect sensors are not
correctly connected
• Examine the cable connections for
the axis, and correct any loose
connections
• Use the electrical drawings to
make sure the Hall Effect sensor
phasing is correct
The axis amplifier is bad
• Replace the amplifier
Doors are open
• Close the doors tightly
The axis runs
away
Axis encoder does
not work
Motor power connections
are wired incorrectly
• Use the electrical drawings to
make sure the phasing is correct
Axis encoder/brake cable
is loose or not connected
• Examine the cable connections,
and repair any loose connections
The axis amplifier is bad
• Replace the amplifier
Revision G / November 2021
Page 31 of 60
Problem
Other Symptoms
Possible Cause
Corrective Action
Pneumatic
actuator failure
Pneumatics work
slowly
Air lockout valve on the
workcell is in the OFF
position
• Turn the air lockout valve to the ON
position
Not sufficient air pressure
• Examine and adjust the system
pressures to the correct values,
refer to the Machine Specific
Information for pressure settings
The air line is bent or
blocked
• Repair any tight bends or
restrictions in the air lines
A fitting or tube
connection is loose
• Tighten loose connections
• Examine flow control fitting
The air line is frayed or
damaged
• Replace the damaged air line(s)
Sensor is not positioned
correctly
• Adjust the sensor location
Part in place
sensor failure
Cable is loose or not
connected
Gain Adjustment
• Examine the cable connections,
and repair any loose connections
• Refer to sensor manual
Conveyor does
not run
Conveyor belt stuck to rails
• Clean or replace belt
No power to
conveyor motor
Control relay not energized
or Power On light not
illuminated (Certain
Models)
• Examine voltages and connections
• Examine conveyor power fuse
Exhaust fan
does not run
No air flow
The motor overload relay,
OL-1, is in the tripped state
• Reset the exhaust fan overload
relay
• Examine FU-5 in the electrical
enclosure
Insufficient air flow
capacity in the factory air
ducts
• Install larger air ducts to increase
air flow
• Reset the exhaust fan overload
relay
The filter and
ducting are fine and
the motor
temperature is
normal.
The overload relay current
setting has been changed
• Make sure the current setting on
the overload relay is correct. Refer
to exhaust fan setup for more
information
• Examine the overload relay for a
tripped flag. Push the reset button
to reset the relay
Figure 18: Systems Fault Diagnosis
Revision G / November 2021
Page 32 of 60
Maintenance
Overview
Do the preventative maintenance as shown in the table below to increase the life of the
workcell and make sure every run is high quality.
Note: Only qualified personnel should do workcell maintenance.
Schedule
Type Of Service
Service Area
Every Shift
Weekly
Monthly
Quarterly
Dispense
Equipment
Examine all
fluid
pressures and
dispense
weights
Clean material buildup on
fixtures and locating
surfaces
Examine for leaks around
compression fittings, tighten
or replace if necessary
Examine the fluid
delivery lines for
excessive wear
Examine the
inline material
filter for clogs
Electro-
mechanical
components
Examine the motors for
overheating and smooth
operation
Examine wires, pneumatic
lines, and material lines for
wear
Apply lithium grease
(JIS Type 2) to the ball
screw slides
Examine all
moving cables
for excessive
wear
Conveyor
System
Clean
conveyor
belts
Clean material and dust
buildup from the sensors
Examine the conveyor
belts for wear
Conveyor System
Chain: Lubricate chain
with Darmex 773ND or
equivalent
Conveyor System
Rails: Clean and
lubricate with Mobil
DTE-24 or equivalent.
You can also use a thin
film of the conveyor
grease, Darmex 773ND
or equivalent.
