1Introduction

1.1 Traceability

In the printed circuit board production industry, traceability means the ability to trace back production

data over long periods. For example, the traceability data can be used even after years to determine

which component was used in a particular batch/packaging unit, to place a certain board.

Traceability covers all the components needed to generate traceability data in a placement line. This in-

cludes the release of traceability data at the individual stations, generating traceability data on line level,

archiving/visualizing the same traceability data in Trace Monitor, and transferring the traceability data to

superior systems.

If required by the customer, splice sensors and board barcode readers can also be integrated into the

traceability system.

1.2 Target Group

SIPLACE Traceability is designed for trained personnel and system administrators at the customer com-

pany. Users are expected to be thoroughly familiar with SIPLACE machines and the SMD process.

NOTICE

Traceability data quality

The traceability software is subjected to endurance tests before being released. (Virtual) PCBs

are produced during the endurance tests over 48 hours. The traceability data produced thereby

has a quality of 0 dpm.

In real production environments, the quality of the traceability data depends on the entire proc-

ess chain.

By means of measures in the software (e.g. splice monitor), errors from the operational level

and from the hardware process chain will be intercepted.

In rare cases, however, it is possible that traceability data is faulty.

The following error situations are known:

►missing splice point (configurations with splice sensor)

►scanning of wrong packaging unit information

NOTICE

Trace Host no longer included

SIPLACE Trace Host is no longer part of the Traceability 3.3 product CD. The database option

is now made available via the SIPLACE Trace Service and can be configured with the Trace

Service Manager.

CAUTION

Qualified Personnel

This work may only be carried out by staff with appropriate training for the specific software part.

►All tasks must be carried out by trained and qualified personnel. All warning, caution and

danger notes MUST be observed!

Introduction

Scope of Delivery

28 SIPLACE Traceability 3.3

1.3 Scope of Delivery

▪ SIPLACE Traceability Basic License V3.x (license only) [00169566-01]

▪ SIPLACE Traceability Upgrade-License V3.x (license only) [00169567-01]

▪ SIPLACE Traceability Machine Connection (full version [00169578-01] or Upgrade [00169579-01])

▪ SIPLACE Traceability V3.3 Media Package [00169569-01]:

1 Traceability 3.3 CD [00388698-01]

– Installation SIPLACE Trace Service

– Installation SIPLACE Trace Monitor

– Installation Traceability Option for SIPLACE Explorer

– Activation of traceability data generation at the station

SIPLACE NET Support V1.12 [00388691-01] with DVD1 Support Media V1.12 [00388693-01] and

DVD2 Support Media V1.12 [00388694-01]

Installation of system requirements:

– Java 2 Java Runtime Environment 1.6

– SQL Server 2008 SP1 Express

– Tomcat Web Server 5.5

– Microsoft.NET 3.5 SP1 Framework

– Microsoft Internet Explorer 7.0, 6.0 SP2

– Adobe Acrobat Reader 9.3

– License Manager 2.2 SP1

Basic documents:

– Installation Manual SIPLACE Traceability 3.3 (item no.: 00196785-xx [English])

– Software Version Description SIPLACE Traceability 3.3 (item no.: 00196784-xx [English, Ger-

man])

– User Guide SIPLACE Traceability 3.3 (item no.: 00196782-xx [German] / 00196783-xx [English])

NOTICE

This software manual

We would like to draw your attention to the fact that the contents of these software instructions

are not part of a previous or existing agreement, commitment or legal contract, neither is this

intended to modify one of the above. All obligations may be taken from the appropriate sales

contract, which also contains a complete and valid warranty agreement. These contractual

statements are neither extended nor restricted by this software guide.

NOTICE

Navigation guide

Please use the document “Navigation Guide for the Installation Procedure of SIPLACE Soft-

ware Systems” (Item no. 00195050-xx) to guide you through the documentation. The Naviga-

tion Guide and all the other documents referred to can be found on one of the Support Media

DVDs (item no. 00388693-xx or 00388694-xx), supplied with each software product.
