Page 30

HCSxxx

Fig.37: HCSxxx

1) The Clock signal is usually on S2 pin, the Data signal

is usually on PWM pin.

SPD5118

Fig.38: SPD5118

1) In offline mode an iternal supply voltage from the

programmer has to be used, because a POR with HSA

pin connected to GND is needed. For this mode the

HSA pin of the device can be connected to the L pin

of the programmer. In normal mode the HSA pin do

not have to be connected to the programmer. A write

protection can be disabled in the offline mode only in

registers of MR12, MR13.

2.7

Technical Specifications

2.7.1 Limit Values

Operating temperature

min. 0°C

max. +55°C

Storage temperature

min. -40°C

max. +85°C

Voltage at any pin

min. -0.5V

max. 6.5V

Maximum current on I/O pin

50mA

ESD protection (HBM model)

±4kV kontakt

±8kV vzduch

Table12: Limit values

Pin P configured as an output has a voltage within a

range of +6.5V to +17V.

Page 31

2.7.2 Operating

Specifications

Important Warning

Failure to respect these parameters may

damage the programmer or the connected

computer.

VDD feeding voltage

supplied by programmer

1.8V to 5.5V

VDD feeding voltage

supplied by application

1.8V to 5.5V

VDD external feeding voltage

for communication at limited

speed

1.2V to 5.5V

Maximum current drawn

from VDD

100mA

Maximum current drawn

from VPP

100mA at 7V

10mA at 17V

Maximum current drawn

from I/O pin

4mA @ VDD = 1.8V

16mA @ VDD = 4.5V

Maximum current drawn

from all I/O pins

simultaneously

100mA

Allowed input voltage on pins

0 to 5.5V

P pin output voltage

Adjustable from 6.5V to 17V or

logic levels

VIL input voltage

max. VDD x 0.3V

VIH input voltage

min. VDD x 0.7V

VOL output voltage

max. 0.55V @ VDD=4.5V

@I=4mA

typ. 0.1V

VOH output voltage

min. 3.8V @ VDD=4.5V @I=4mA

typ. VDD - 0.1V

Resistance to short circuiting

permanent

Operating system

Windows

32/ 64-bit

USB compatibility

USB 2.0 High-Speed (480Mbps)

USB connector

type B

Dimensions

112 x 64 x 22mm

Weight

60g

Gross weight

230g

Table13: Operating specifications

The programmer can typically communicate at a lower

application’s voltage at a reduced speed.

WindowsXP, WindowsVista, Windows7, Windows8,

Windows8.1, Windows10, Windows11

Page 32

2.7.3 Declaration of

Conformity and RoHS

Declaration of Conformity and RoHS directive documents

are available at
