Table of Contents
3-1
Table of Contents
Main Contents
Table of Contents ................................................................................................ 3-1
Main Contents ................................................................................................ 3-1
Chapter 3. Transfer & Installation Procedure ........................................................... 3-3
3.1. Machine Installation ............................................................................... 3-3
3.1.1. Unloading Machine ................................................................................. 3-3
3.1.2. Unpacking and Transportation ................................................................ 3-4
3.1.3. Machine Installation ................................................................................ 3-6
3.1.4. Installation of Parts ............................................................................... 3-10
3.1.5. Pneumatic Pressure Setup and Cable Connection ................................3-11
3.1.6. Power Connection ................................................................................ 3-13
3.1.7. Motor I/O Check ................................................................................... 3-16
3.1.8. Communication Interface Between Machines ....................................... 3-17
3.1.9. Warming Up .......................................................................................... 3-19
3.2. Machine Installation ............................................................................. 3-20
Transfer & Installation Procedure
3-3
Chapter 3. Transfer & Installation Procedure
When installing the machine newly, observe the following procedure.
Warning
Installation or startup by an inexperienced operator may
damage the machine or cause injury. The installation or
startup operation must be performed by our designated C/S
personnel.
3.1. Machine Installation
3.1.1. Unloading Machine
3.1.1.1. Required Tools
Forklift
Safety fence
3.1.1.2. Unloading Procedure
1. The personnel in charge of installation and commissioning must check the details of shipment
with the Production Management Department and inform the customer of expected arrival time
before leaving for the installation site.
2. After arriving at the site, perform a visual inspection of the exterior of the machine before
unloading (check for crushing of the box, etc.).
3. Check safety related items before unloading the machine. Perform safety measures by
installing a safety fence etc., if necessary. (Example: working in a high location.)
4. The personnel of the Business Department shall receive the delivery certificate and forms from
the operator and check the state and quantity of the machines before signing the delivery forms
and then finishes the machine delivery and acceptance procedure with the operator.
5. When unloading the machine, give instructions to ensure the forklift does not damage the
machine. Also, ensure those responsible for unloading and transportation understand the
precautions to be observed when handling the weak parts of the machine. Unload the machine
using only forklift and corresponding jigs and devices.
