SQL Server 2014 / Installation Manual 11/2015 Edition
6
2 Scope of Delivery
This document describes the manual procedure to install Microsoft ® SQL Server 2014 Standard
Edition with default settings for usage of SIPLACE software products for SIPLACE computer
systems.
For this documentation, a 64-bit operating system along with a 64-bit SQL Edition will be used, but
you may use this documentation to install a 32-bit SQL Edition on a 32-bit operating system, too -
the basic steps are the same.
Further customization settings (e.g. modification of database settings) will be done by the specific
product installation setups. Subject of this document is a first-time installation on fresh systems (no
upgrade).
SQL Server 2014 / Installation Manual 11/2015 Edition
7
3 Requirements
This installation manual assumes:
– Basic knowledge in administration of Windows-based computers
– Administrative permissions on the computer
– Access to the appropriate SIPLACE Net Support Media (V2.2 or later) for installation of SQL
Prerequisites or basic knowledge to install packages required by SQL
– Access to the Media Package of SQL Server 2014 Standard Edition
NOTICE
Windows XP and Windows Server 2003 are not supported anymore
Additionally to the requirements of this documentation, the installation of SQL has own,
specific requirements.
These requirements are described on the following web page (you have to select the
SQL version):
http://msdn.microsoft.com/en-us/library/ms143506.aspx
In particular, SQL Server 2014 does not support Windows XP and Windows Server
2003! Therefore, to install and use SQL Server 2014 for the current SIPLACE software
environment, you have to install at least Windows 7 SP1 / Windows Server 2008 R2 or
newer.
SQL Server 2014 / Installation Manual 11/2015 Edition
8
4 Installation
4.1 Installing SQL Server 2014 Prerequisites
To prepare for installation of SQL Server 2014, some software components have to be installed or
updated.
For SQL Server 2014, following software is required:
– .Net Framework 3.5 SP 1
– .Net Framework 4.0
– PowerShell 2.0
The normal procedure of installation of these components might be difficult, depending on the
Operating System (OS) you use and the components you have already installed. Some operating
systems have certain versions of these components integrated and installation of some
components might require other packages, like Windows Installer, to be updated.
To simplify installation of SQL Server Prerequisites, the Prerequisite Analyzer from SIPLACE Net
Support Media provides own profiles for preparation.
NOTICE
Basic knowledge in use of Support Media and Prerequisite Analyzer required
This documentation assumes you know the basic usage of Support Media and
Prerequisite Analyzer. If not, you should make yourself familiar with Support Media
before proceeding. We recommend reading the appropriate documentation which is also
provided on Support Media.
► Insert the SIPLACE Net Support Media (V2.2 or later).
► If not started automatically, start the launcher application.
► Select Prerequisite Analyzer in the launcher application.
► Step through the Prerequisite Analyzer, until the Product Selection page.
