S t ation Sof tware V ersion 705.04 SP2 Sof tware V ersion Description S t ationssof tware-V ersion 705.04 SP2 Sof tware- V ersionsbeschreibun g Ausgabe 06/2012 Edition

Station Software Version 705.04 SP2

Software Version Description

Stationssoftware-Version 705.04 SP2

Software-

ersionsbeschreibun

Ausgabe 06/2012 Edition

All names identified by ® are registered trademarks of the ASM Assembly Systems GmbH & Co. KG. The

remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes

could violate the rights of the owner.

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information given in this publication is reviewed regularly and any necessary corrections are included in

subsequent editions.

ASM Assembly Systems GmbH & Co. KG Item-no.: 00196770-04

Rupert-Mayer-Strasse 44

81379 München

Germany

www.siplace.com

Alle mit dem Schutzrechtsvermerk ® gekennzeichneten Bezeichnungen sind eingetragene Marken der ASM

Assembly Systems GmbH & Co. KG. Die übrigen Bezeichnungen in dieser Schrift können Marken sein, deren

Benutzung durch Dritte für deren Zwecke die Rechte der Inhaber verletzen kann.

Wir haben den Inhalt der Druckschrift auf Übereinstimmung mit der beschriebenen Hard- und Software geprüft.

Dennoch können Abweichungen nicht ausgeschlossen werden, sodass wir für die vollständige Übereinstimmung

keine Gewähr übernehmen. Die Angaben in dieser Druckschrift werden regelmäßig überprüft und notwendige

Korrekturen sind in den nachfolgenden Auflagen enthalten.

ASM Assembly Systems GmbH & Co. KG Artikel-Nr.: 00196770-04

Rupert-Mayer-Straße 44

81379 München

Deutschland

www.siplace.com

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

Contents

1 Brief description 5

2 Scope of delivery 6

2.1 Software components..........................................................................................6

2.2 Hardware components.........................................................................................6

2.3 Languages...........................................................................................................7

3 Important information when upgrading from station software versions

as of 60x 8

3.1 New concept for operating – new user interface..................................................8

3.2 Behavior of the machine start key........................................................................9

3.3 SITEST Functions................................................................................................9

3.4 Calibrating the machine.......................................................................................9

3.5 User classification – new activity levels.............................................................10

3.6 User settings, machine options and software options........................................10

4 Features of the 705.04 SP2 station software version 11

5 Hardware specifications 12

5.1 Supported feeder types .....................................................................................12

5.2 Digital camera systems......................................................................................13

5.2.1 Component cameras .........................................................................................13

5.2.2 Board cameras ..................................................................................................13

5.3 Component range..............................................................................................14

6 SIPLACE software environment 15

6.1 SIPLACE Pro programming system Version 9.3 ...............................................15

6.2 SIPLACE OIS Version 9.3 .................................................................................15

6.3 SIPLACE Setup Center Version 4.1 ..................................................................15

6.4 SIPLACE Traceability Version 3.3.....................................................................15
