Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
D1-69191553 Machine stopped during placement with an exception and needed a reboot
(when placing high components out of MTC).
D1-69279620
D1-70795738
An orange icon for feeder mismatch was displayed on the GUI but no
difference was visible.
D1-69413619
D16159-2426
It was possible to adjust the feeder pitch on the Operator activity level.
D1-69439913
D1-68775501
D16159-2426
A CPP placement head touched the placed board on an X4 placement
machine.
D1-69803411 Problem with Language Pack. Characters were not readable after switching
from English to Polish.
D1-70436501 On an SX4 placement machine an axis warning was displayed after the
reference run during booting.
D1-70445512 The pressure control valve blew a 0201 component out of the component
pocket.
D1-70811301 "Reading barcode" in the "Manual Operations" did not work for PCB Barcode
with PCB camera.
D1-71020801 A 01005 component was incorrectly placed because of faulty tolerance class.
D1-71187163
D1-60414201
D1-68210501
D1-70474001
D1-71103401
A CPP placement head placed a 0201 component with high force. Thereafter,
the component stuck in the nozzle.
D1-71621601 Incoming SMEMA signals were not evaluated on the GUI.
D1-71692897 The required function (changing fixed conveyor rail) was not performed, if the
machine was in production mode before and the operator then clicked on
"Stop production - Restart" in the latest function.
D1-72081601 The station software hung up after a software update.
D1-72982411 When a component shape was taught in the component shape wizard after
having upgraded the station software, the tolerance fell to 1% of the overall
size.
D1-73008901 As a second gantry was re-railed on an SX2 placement machine and the GCU
was not plugged, the machine was operated as an SX1. If gantry 1 then was
moved to the service position it could possibly touch gantry 2.
D1-73492701 Teaching of placement position and placing with high force did not work
together.
D1-73635751 The machine started with an unspecified hardware error for the conveyor E/A
module.
D1-73966879 The machine reported communication failure between two Y-axes.
D1-74037741 After components were taught in Chinese language, the station software hung
up during the robustness analysis.
D1-75321705 Error messages 30507 (hardware warning) and 30576 (unspecified hardware
error) were displayed when the machine was started.
D16006-11801 On an SX-series placement machine the tables could not be removed for a
setup change.
D16120-4012 An SX4 placement machine with hung up during vacuum tooling.
D16198-8327 Bad quality of a placed board (missing components and spattering).
25
Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
D16223-6011
D1-73633618
Unspecified hardware error on an X4I placement machine.
D16247-4808 An X4I placement machine hung up during the component check by Vision.
D16422-8207 Sporadically, an SX-series placement machine hung up and had to be
rebooted.
Table 8-1: Corrected errors
26
Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
9 Important terms and abbreviations
ACT Accuracy Check Tool
C&P Collect & Place
CPP Collect & Place & Pick & Place
DC Dual Conveyor
DX1/DX2 Machine type with 1 or 2 gantries
DX4 Machine type with 4 gantries
EDIF Electronic Design Interchange Format
FCCS Field Camera Calibration System
GCU Gantry Control Unit (new electronic concept for X4I)
GUI Graphical User Interface
HCU Head Control Unit (new electronic concept for X4I)
HFH High Force Head
HW Hardware
MTC Matrix Tray Changer
OIS Operator Information System
PA Processing area
PCB Printed circuit board
QC Quad Lane Conveyor
SC Single Conveyor
SC SIPLACE Setup Center (external setup station)
SSI SIPLACE Station Interface
SW Software
SX1/SX2 Machine type with 1 or 2 gantries
SX4 Machine type with 4 gantries
VC Vision computer
VCU Vision Control Unit
WPC Waffle Pack Changer
X2 Machine type with 2 gantries
X3 Machine type with 3 gantries
X4 Machine type with 4 gantries
X4I Machine type with 4 gantries
