Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

– The maximum height for components to be measured is 17 mm.

– High-reflection leads can impact negatively on measurement.

– Components which have both balls and leads cannot be measured.

– Coplanarity measurement is not carried out at the placement angle. The component is

presented to the coplanarity laser at 0°.

– Coplanarity measurement impairs placement performance.

Long Board Option on DX4

– The long boards must not be placed between two machines, i.e. the board is not unloaded from

the preceding machine until it can be completely loaded into the downstream machine.

– No board is buffered in the intermediate section.

C&P12 placement head

– Not supported on the DX4-, X-series and SX-series placement machines.

– The component sensor is not supported.

– No validated procedure for placement with 0201 or 01005 components.

– No temperature compensation.

– Placement machines on platform PII+ with C&P12 placement heads cannot be upgraded.

– Placement machines with A364 and C&P12 configurations are not supported.

– No C&P12 nozzle changer may be set up in the C&P20A and C&P12 combination.

– The fast head exchange feature is not supported.

Alternative components

The placement of alternative components is only possible in combination with SIPLACE Setup

Center.

LED placement, "Empty feeder" function

– A valid SIPLACE Pro job containing the feeder and the nozzle configuration has to be specified

in order to empty the feeder.

– Generally, a batch change does not require another nozzle, as only the illumination class

changes but not the component geometry. If the product is changed and another LED is

required (geometrical shape) the feeder has to be changed, too (different geometry of the feed

track).

– If the function is used, the feeder filling level is not consistent anymore. Subsequently, the filling

level has to be manually adjusted over a new packaging unit to continue placing.

– Components that are rejected during production (Vision errors, cleaning cycle etc.) are not

rejected into the additional reject bin on the component table, but into the “general” reject bin.

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

Teaching of placement positions during placement

– Viewing the whole line, it is not possible to teach all placement positions of a board on a single

placement machine. Only the placement positions that in fact are placed on a station are listed

for selection. I.e., in order to correct all placement positions, the board has to be moved

through the whole line.

– No integrity check is performed at the station after the teaching action. As the station restores

to SIPLACE Pro and a download subsequently takes place to the other placement machines,

an integrity check is performed by SIPLACE Pro. This might fail, if it is impossible to go to the

resulting placement positions.

Brightness calibration of digital camera systems

– Only conveyor lane 1 is used for the FCCS calibration.

– No teaching of fiducial positions or structures on the calibrating jigs.

– No FCCS calibration for a line, solely for a single machine.

No machine stop at "track empty" errors in I-placement mode

– If the Machine stop at pickup error option is deactivated, no machine stop errors caused by

pickup errors are transmitted to OIS and Explorer. In this case, the reporting of idle times

caused by pickup errors is not possible anymore.

– If the placement machine does not stop it may happen that it in fact does not place anymore (it

waits for he feeders to be filled) but is not stopped either (e.g. boards might still be loaded).

This state is then displayed as "Producing" and not as stopped in OIS.

Set indicator lamp

The feature is only supported on the SX-series and DX-series placement machines.

Adjustable minimum track width

– The feature is only supported on the SX-series and DX-series placement machines.

– In the Quad Lane conveyor mode there is only one adjustable value for each track pair.

Random setup for tray feeders

The feature only works in combination with SIPLACE Setup Center.

Automatic storage of feeder parameters

– Due to the system the feature cannot currently be reasonably used for:

– recipe-based production (PCB barcode)

– station wise download

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

8 Corrected errors

The 705.04 SP2 station software version contains all the error corrections of the previous versions

701.01 – 705.04 SP1. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-62055103 Incorrect control of the lamp indicators.

D1-66221447 The zero point corrections could not be transferred to the software by the

intermediate distributor.

D1-66510192 An error was displayed on an 2x8 mm feeder (red LED). In spite of this, the

machine picked up from this feeder.

D1-67655607

D1-69213143

D1-70140490

Error message "Cover foil broken: component:" was still displayed after the

error had been fixed.

D1-67778301

D16058-4811

D16120-2861

Problems while measuring the component via the stationary camera. In order

to avoid scattered light, the component sensor of the CPP head will therefore

be switched off before the component centering with the stationary camera or

the coplanarity measurement take place.

D1-68389204 Field test 705.04.SP1: Software hung up during production.

D1-68686001

D16275-119525

Possibility of placing wrong components in partial setups.

D1-68715501 The machine reported a fatal error after a pickup error.

D1-68759501 Component broke during dipping process.

D1-68778701 Sporadically, a hardware warning was displayed after reboot.

D1-68824501

D1-69455601

D1-69693501

D1-70795701

D1-70822701

D1-70844901

D1-71124601

D1-71551914

Hardware warning not significant.

D1-68887201

D1-69192130

Pickup problems with selected segments. After a reference run it was ok.

D1-69038301 The station software hung up after the operator tried to reactivate an

automatically deactivated segment on a C&P20 head.

D1-69038350 A software protection fault occurred on an X4I placement machine.

D1-69038398 Protocol violation when HCU controlled the C&P20 DP axes (embedded SW +

station software).

D1-69151101 SX placement machines: HCU does not answer and communication is

interrupted; after a short period of time it is reactivated (embedded SW).

D1-69183313

D16334-2955

Unhandled exception on an SX2 placement machine. This happened when

referencing the star axis manually failed.

D1-69183365 Feeder warnings were displayed on the screen although everything was

working well.
