Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
NOTICE
An overview for operating the station software is given in the "Getting Started" manual fo
r
the 701.02 version (Order Number: 00195685-02). There, you can also find examples to
some functions.
Detailed information on special functions can be found in the online help of the station
software.
3.2 Behavior of the machine start key
In the 70x station software version the behavior of the start key can be set:
The following settings are available:
– Start production automatically (Default)
If the start key is pressed, the production is started automatically.
– Do not change production status (e.g. for testing the machine)
If the start key is pressed, the circuit is closed, but the production is not directly started.
NOTICE
The machine functions can be started directly via the GUI, irrespective of the start key
mode. If the circuit is already closed, no further confirmation via the start key of the
machine is required.
For further information on the start key behavior, see the online help of the station
software.
3.3 SITEST Functions
SITEST is no more available as a separate tool. The SITEST functions are implemented in the 70x
station software, if the Machine Service activity level is activated.
3.4 Calibrating the machine
As of the 70x station software version the machine can be calibrated with minimal operator
interaction.
First select all calibration steps to be processed. Then change the settings using the software
wizard. Afterwards you start the calibration without any further user intervention.
9
Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
3.5 User classification – new activity levels
The activity levels have been changed in the 70x station software version. The following 4 activity
levels exist:
– Basic Production
– Advanced Production
– Machine Service
– SIPLACE Service
NOTICE
For a detailed description of the user classification and changing the activity levels, see
the "Getting Started" manual (order number: 00195685-02).
3.6 User settings, machine options and software options
There is no menu bar on the GUI of the 70x station software version.
The user settings, the software options and the machine options can be found in the Settings
(Icon
) view.
NOTICE
For a detailed description of the settings, see the online help of the station software.
10
Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition
4 Features of the 705.04 SP2 station software
version
NOTICE
Detailed information on special functions can be found in the online help of the station
software.
All features of the 701.xx - 705.04 SP1 station software versions are also supported in the 705.04
SP2 station software version.
