Station Software 705.04 SP2 / Version De scription Ausgabe 06/2012 Edition 7 Restrictions No support for: – S-tables – S-feeders – C&P6 placement heads – 2D coplanarity – Recipe size controlled assembly X-Feeder Beca…

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

6 SIPLACE software environment

6.1 SIPLACE Pro programming system Version 9.3

The SIPLACE Pro Version 9.3 programming system supports the SIPLACE X-series, SX-series

and DX-series placement machines with the 705 station software version.

NOTICE

For a detailed description of the programming system, see the SIPLACE Pro 9.3 version

description and the online help system.

6.2 SIPLACE OIS Version 9.3

Software version 9.3 of the monitoring system SIPLACE OIS supports the SIPLACE X-series, SX-

series and DX-series placement machines.

NOTICE

detailed description can be found in the software description "Getting started with OIS"

and the online help system for OIS.

6.3 SIPLACE Setup Center Version 4.1

Software version 4.1 of the SIPLACE Setup Center supports the SIPLACE X-series, SX-series and

DX-series placement machines.

NOTICE

A detailed description can be found in the software description "Getting started with

Setup Center" and the online help system for Setup Center.

6.4 SIPLACE Traceability Version 3.3

Software version 3.3 of SIPLACE Traceability supports the SIPLACE X-series, SX-series and DX-

series placement machines.

NOTICE

A detailed description can be found in the “Traceability User Guide".

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

7 Restrictions

No support for:

– S-tables

– S-feeders

– C&P6 placement heads

– 2D coplanarity

– Recipe size controlled assembly

X-Feeder

Because of the mirrored gantry configuration, the number of the available tracks on gantry 2 and 4

on the X4I, SX4 and DX4 placement machines are restricted, not all of the tracks can be reached

by the placement heads. Feeders set on non-reachable tracks are deactivated automatically.

Number of nozzle changer magazines

Because of the mirrored gantry configuration, the number of configurable nozzle changer

magazines on gantry 2 and 4 on the X4I, SX4 and DX4 placement machines is limited to 4

magazines.

Nozzle types

– Nozzle types of the 4xx, 5xx, 8xx and 9xx series are not supported by the X4I, SX4 and DX4

placement machines.

– Nozzle types of the 4xx, 5xx, 8xx, 9xx, 10xx, 11xx and 12xx series are not supported by the

CPP placement head.

Board barcode

– The board barcode is limited to 40 characters.

– Quad Lane conveyor is not supported in combination with board barcode.

Machine zero point

Because of the geometric configuration the X4I and SX4 placement machines have a separate

zero point for each gantry. For the correlation of both machine zero points in one placement area,

mapping must be performed.

Fiducial patterns

Asymmetric fiducial patterns (e.g. triangles) can currently only be used if the board is processed at

an orientation of 0° in the machine.

Station Software 705.04 SP2 / Version Description Ausgabe 06/2012 Edition

X-table

An additional table fiducial is necessary for the gantries 2 and 4 on the X4I and SX4 placement

machines.

Twin Head/HFH

– Twin Head/HFH are not supported on the X4I and DX4 placement machines.

– Not vacuum pump compatible.

– Not all pickup, dip and placement positions are accessible for both segments on the SX1/SX2

and SX4 placement machines.

CPP placement head

– Restrictions for the X2, X3, X4, X4I and SX4 placement machines can be found in the

correspondent User Guides to the X-series and in the Version Description to SIPLACE Pro.

– Not vacuum pump compatible.

– Not supported on DX series placement machines.

Reduced air consumption with vacuum pump

No support for CPP placement heads and Twin Head.

Automatic tray feeding

The function is not supported on the X4I, SX4 and DX4 placement machines.

Quad Lane conveyor

– Quad Lane conveyor is not supported on the X2, X3, SX1/SX2, DX1/DX2 and DX4 placement

machines.

– A Quad Lane job from SIPLACE Pro will always download one recipe for both sub-lanes. It is

not possible downloading one recipe to sub-lane xL and another recipe to sub-lane xR.

– If a single board is downloaded in Quad Lane transport mode, it has to be produced on the

outer sub-lane of the lane pairs, i.e. on 2L or 1R.

– X4 and X4I placement machines: The outer side panels of the sub lanes 2L and 1R are set to

21 inch in the outer position. However, if the placement machines are not exactly in line to each

other, boards might get stuck on handing them over. Therefore the outer side panels can be

manually extended to an over-width of 540 mm. In SIPLACE Pro the maximum width remains

by 535mm.

– Barcode scanner is not supported.

– Due to the reachability of the board camera, asynchronous operation mode with maximum

width is not possible on the X4I placement machine (instead of that, operation in I-Placement

mode).

– Depending on board geometry and placements there might be increased interference with the

gantries in I-Placement mode.

– I-Placement mode solely on three conveyor lanes is not supported.

– SIPLACE Traceability and TraceHost are not supported.

– 3rd party traceability systems are only supported on OIS SIS basis.
