MANUAL (TCM-X Series) SPECIFICA TIONS 0304-001 Tg0590-PM-SO INSTRUCTION MANUAL SPECIAL SPECIFICA TIONS C-S210-05 Placement Position T each TCM-X Series
MANUAL
(TCM-X Series)
SPECIFICATIONS
0304-001 Tg0590-PM-SO
INSTRUCTION MANUAL
SPECIAL SPECIFICATIONS
C-S210-05
Placement Position Teach
TCM-X Series
Before Use
We are grateful to you for purchasing these special specified
products.
Please keep in mind the following items before use.
1. Please read this instruction manual carefully for correct use of
these special specified products.
The following warning signs are classified into three catego-
ries according to the degree of danger.
Please fully understand the meaning of each sign for safety
precautions.
This indicates a potentially hazardous situation
which, if not avoided, may result in injury or physi-
cal damage.
CAUTION
DANGER
This indicates an imminently hazardous situation
which, if not avoided, will result in death or seri-
ous injury.
This indicates a potentially hazardous situation
which, if not avoided, could result in death or seri-
ous injury.
WARNING
This manual is made of recycled paper.
0304-001 1 Tg0590-PM-SO
SOM-1619-001
Before Use
INSTRUCTION MANUAL
Placement Position Teach
C-S210-05
TCM-X Series
SPECIAL SPECIFICATIONS
Contents
Page
0301-002 3 Tg0590-PM-SO
Contents
Before Use...............................................................................................1
Contents ...................................................................................................3
1. Scope ............................................................................................. 4
2. Data to be Taught........................................................................... 4
3. Notes on Teaching Operation ........................................................ 5
4. PCB Origin Offset Teach ................................................................ 6
4.1 "PCB Origin Offset Teach" Tab Sheet ...................................... 7
4.2 PCB Origin Offset Teach Operation Procedure........................ 10
5. Placement Position Teach.............................................................. 14
5.1 "Placement Position Teach" Tab Sheet .................................... 15
5.2 Placement Position Teach Operation Procedure ..................... 17
