42
General Specifications
System specifications
Scanning inputs
Analog:
34921A, 34922A, 34923A, 34924A, and 34925A multiplexer channels
Digital
34950A/52A digital in and totalize
Scan triggering
Source
Interval, external, button press software, or on monitor channel alarm
Scan count
1 to 50,000 or continuous
Scan Interval
0 0 99 hours; t ms step size
Channel delay
0 to 60 seconds per channel; 1 ms step size
External trig delay
< 2 ms. With monitor on < 200 ms
External trig jitter
< 2 ms
Alarms
Analog inputs
Hi, Lo, or Hi + Lo evaluated each scan
Digital inputs
34950A/52A digital in maskable pattern match or state change
34950A/52A frequency and totalize: Hi limit only
Monitor channel
Alarm evaluated each reading
Alarm outputs
4 TTL compatible. Selectable TTL logic Hi or Lo on fail
Latency
5 ms (typical)
Memory
Type
Volatile
Readings
500,000 with timestamp, readable during scan
States
5 instrument states with user label
Alarm queue
Up to 20 events with channel number, reading, and timestamp
System features
Per-channel
Individual Mx+B scaling and calculated real-time min/max/average
Power fail recovery
Save switch states
Relay maintenance
Counts each relay closure and stores on module. User resettable
Real-time clock
Battery-backed, 20-year typical life
Line power
Power supply
Universal 100 Vac to 240 Vac
Power line frequency
50 – 60 Hz ± 10% automatically sensed
Power consumption
150 VA
Environment
Operating environment
•
0 - 55°C, 2000 m, maximum humidity is 80% RH at 40˚C and decreases
linearly to 37% RH at 55˚C
2
•
IEC 60664-1 pollution degree 1 or 2
•
Refer to 34980A User's Guide, Chapter 4, Module Considerations section for
the details of Environmental Operating Limits (current and power dissipation)
for the Plug-In Modules in Pollution degree 1 or 2 environments.
Storage environment
- 40 °C to 70 °C
1
Note:
1. Storage at temperatures above 40 °C will decrease battery life
2. From 40°C to 55°C, the maximum % Relative Humidity follows the line of constant dew point.
43
Mechanical
Mainframe dimensions
133 H x 426 W x 341 D mm (5.25" x 16.8" x 14")
Full rack, 3 units high
Mainframe weight
8.8 kg (19.6 lbs)
Module dimensions
Approximately 170 W x 270 D x 27 H mm (6.69" x 10.62" x 1.06")
Module weights
0.73 to 1.18 kg (1.6 to 2.6 lbs
Terminal block dimensions
170 W x 165 [or 105] D x 25 H mm (6.69" x 6.49" [or 4.13”] x 0.98")
Terminal block weights
0.27 to 0.36 kg (0.6 to 0.8 lbs)
Regulatory
Safety and EMC
Refer to Declaration of Conformity for the latest revisions of regulatory
compliance at: www.keysight.com/go/conformity
Recommended software
•
Keysight IO Libraries Suite 2019 or greater: www.keysight.com/find/IOLibraries
•
BenchVue: www.keysight.com/find/benchvue
•
BenchVue DAQ: www.keysight.com/find/benchvuedaq
The BenchVue platform is a prerequisite for the BenchVue DAQ application.
Software driver support for programming languages
Software drivers
IVI-C and IVI COM for Windows 7/8.1/10 and LabVIEW
Compatible programming tools and environments
•
Keysight VEE Pro
•
National Instruments Test Stand, Measurement Studio, Lab Windows/CVI,
LabVIEW, Switch Executive
•
Microsoft Visual Studio.NET, C/C++, Visual Basic
Keysight BenchVue Data Acquisition Control and Analysis Application system requirements
Operating system
•
Microsoft Windows 10: 32-bit & 64-bit (Professional, Enterprise, Education,
Home versions).
•
Microsoft Windows 8 & 8.1: 32-bit & 64-bit (Professional, Enterprise, Core).
•
Microsoft Windows 7: SP1 and later 32-bit & 64-bit (Professional, Enterprise,
Ultimate, Home Basic, Home Premium)
Processor
1 GHz or faster (2 GHz or greater recommended)
RAM
RAM: 1 GB (32-bit) or 2 GB (64-bit) (3 GB or greater recommended)
Display
1280x1024 minimum for single instrument view (higher resolution recommended
for multiple instrument view)
Computer Interfaces
LXI
10/100Base-T Ethernet (Sockets, VXI-11 protocol, Web user interface)
USB
Standard USB 2.0
GPIB
IEEE-488
Language
SCPI-1999, IEEE-488.2
44
Definitions for Specifications
Specifications describe the warranted performance of calibrated instruments that have been stored for a
minimum of 2 hours within the operating temperature range of 0 °C to 55 °C, unless otherwise stated, and
after a 45-minute warm-up period. Data represented in this document are specifications unless otherwise
noted.
Characteristics describe product performance that is useful in the application of the product but that is not
covered by the product warranty. Characteristics are often referred to as Typical or Nominal values.
•
Typically describes the characteristic performance, which 80% of instruments will meet when
operated over a 20 °C to 30 °C temperature range. Typical performance is not warranted.
•
Nominal describes representative performance that is useful in the application of the product when
operated over a 20 °C to 30 °C temperature range. Nominal performance is not warranted.
Note: All graphs contain measured data from several units at room temperature unless otherwise
noted.
Ordering Instructions
Mainframe – holds up to 8 plug-in modules
Mainframe
Description
Remarks
34980A
Multifunction data acquisition
mainframe
Comes standard with “DMM” option and BenchVue DAQ
BV0006B
BenchVue Data Acquisition
Control and Analysis (DAQ)
BenchVue makes it simple to connect, control instruments, and
automate test sequences. Supported plug-in modules:
34921A, 34922A, 34923A, 34924A, 34925A, 34931A, 34932A,
34933A, 34937A, 34938A, 34952A.
