Mechanical
Mainframe dimensions
133 H x 426 W x 341 D mm (5.25" x 16.8" x 14")
Full rack, 3 units high
Mainframe weight
8.8 kg (19.6 lbs)
Module dimensions
Approximately 170 W x 270 D x 27 H mm (6.69" x 10.62" x 1.06")
Module weights
0.73 to 1.18 kg (1.6 to 2.6 lbs
Terminal block dimensions
170 W x 165 [or 105] D x 25 H mm (6.69" x 6.49" [or 4.13”] x 0.98")
Terminal block weights
0.27 to 0.36 kg (0.6 to 0.8 lbs)
Regulatory
Safety and EMC
Refer to Declaration of Conformity for the latest revisions of regulatory
compliance at: www.keysight.com/go/conformity
Recommended software
•
Keysight IO Libraries Suite 2019 or greater: www.keysight.com/find/IOLibraries
•
BenchVue: www.keysight.com/find/benchvue
•
BenchVue DAQ: www.keysight.com/find/benchvuedaq
The BenchVue platform is a prerequisite for the BenchVue DAQ application.
Software driver support for programming languages
Software drivers
IVI-C and IVI COM for Windows 7/8.1/10 and LabVIEW
Compatible programming tools and environments
•
Keysight VEE Pro
•
National Instruments Test Stand, Measurement Studio, Lab Windows/CVI,
LabVIEW, Switch Executive
•
Microsoft Visual Studio.NET, C/C++, Visual Basic
Keysight BenchVue Data Acquisition Control and Analysis Application system requirements
Operating system
•
Microsoft Windows 10: 32-bit & 64-bit (Professional, Enterprise, Education,
Home versions).
•
Microsoft Windows 8 & 8.1: 32-bit & 64-bit (Professional, Enterprise, Core).
•
Microsoft Windows 7: SP1 and later 32-bit & 64-bit (Professional, Enterprise,
Ultimate, Home Basic, Home Premium)
Processor
1 GHz or faster (2 GHz or greater recommended)
RAM
RAM: 1 GB (32-bit) or 2 GB (64-bit) (3 GB or greater recommended)
Display
1280x1024 minimum for single instrument view (higher resolution recommended
for multiple instrument view)
Computer Interfaces
LXI
10/100Base-T Ethernet (Sockets, VXI-11 protocol, Web user interface)
USB
Standard USB 2.0
GPIB
IEEE-488
Language
SCPI-1999, IEEE-488.2
44
Definitions for Specifications
Specifications describe the warranted performance of calibrated instruments that have been stored for a
minimum of 2 hours within the operating temperature range of 0 °C to 55 °C, unless otherwise stated, and
after a 45-minute warm-up period. Data represented in this document are specifications unless otherwise
noted.
Characteristics describe product performance that is useful in the application of the product but that is not
covered by the product warranty. Characteristics are often referred to as Typical or Nominal values.
•
Typically describes the characteristic performance, which 80% of instruments will meet when
operated over a 20 °C to 30 °C temperature range. Typical performance is not warranted.
•
Nominal describes representative performance that is useful in the application of the product when
operated over a 20 °C to 30 °C temperature range. Nominal performance is not warranted.
Note: All graphs contain measured data from several units at room temperature unless otherwise
noted.
Ordering Instructions
Mainframe – holds up to 8 plug-in modules
Mainframe
Description
Remarks
34980A
Multifunction data acquisition
mainframe
Comes standard with “DMM” option and BenchVue DAQ
BV0006B
BenchVue Data Acquisition
Control and Analysis (DAQ)
BenchVue makes it simple to connect, control instruments, and
automate test sequences. Supported plug-in modules:
34921A, 34922A, 34923A, 34924A, 34925A, 34931A, 34932A,
34933A, 34937A, 34938A, 34952A.
45
Module
Description
Connectors
Optional terminal blocks, cables, connector kits
Multiplexer modules
34921A
40-channel armature multiplexer w/low
thermal offset
(Order 34921T for temp reference)
2 – 50-pin
Dsub, Male
3492xT Terminal block with screw connectors
Y1135A – 1.5 m 50-pin M/F Dsub cable
Y1136A – 3 m 50-pin M/F Dsub cable
Y1139A – 50-pin female solder cup connector kit
34923A
40/80-channel reed multiplexer
34925A
40/80-channel optically isolated FET
multiplexer
34922A
70-channel armature multiplexer
2 – 78-pin
Dsub, Male
3492xT Terminal block, option 001 for solder
connections, option 002 for screw connectors
Y1137A – 1.5 m 78-pin M/F Dsub cable
Y1138A – 3 m 78-pin M/F Dsub cable
Y1140A – 78-pin female solder cup connector kit
34924A
70-channel reed multiplexer
Matrix modules
34931A
Dual 4x8 armature matrix
2 – 50-pin
Dsub, Male
3493xT Terminal block with screw connectors
Y1135A – 1.5 m 50-pin M/F Dsub cable
Y1136A – 3 m 50-pin M/F Dsub cable
Y1139A – 50-pin female solder cup connector kit
34932A
Dual 4x16 armature matrix
34933A
Dual/Quad 4x8 reed matrix
34934A
Quad 4x32 reed matrix
2 – 78-pin
Dsub, Male
34934T Terminal block with screw connectors OR
34934C Configuration block
Y1137A – 1.5 m 78-pin M/F Dsub cable
Y1138A – 3 m 78-pin M/F Dsub cable
Y1140A – 78-pin female solder cup connector kit
General-purpose/actuator modules
34937A
32-channel Form C/Form A general-
purpose switch
2 – 50-pin
Dsub, Male
3493xT Terminal block with screw connectors
Y1135A – 1.5 m 50-pin M/F Dsub cable
Y1136A – 3 m 50-pin M/F Dsub cable
Y1139A – 50-pin female solder cup connector kit
34938A
20-channel 5-amp Form A switch
34939A
64-channel Form A Switch
2 – 78-pin
Dsub, Male
34939T Terminal block with screw connectors
Y1137A – 1.5 m 78-pin M/F Dsub cable
Y1138A – 3 m 78-pin M/F Dsub cable
Y1140A – 78-pin female solder cup connector kit
RF and microwave modules
34941A
Quad 1x4 50-ohm 3-GHz RF multiplexer
20 - SMA
Requires standard 50 ohm SMA RF cables, and
optional 8710-2576 SMA Extender wrench for
connecting SMA connectors
34942A
Quad 1x4 75-ohm 1.5 GHz RF
multiplexer
20 – mini
SMB
Requires mini 75-ohm SMB RF cables, adapters
34945A
Microwave switch/attenuator driver
N/A
Requires 34945EXT and optional Y1150A-Y1155A
distribution boards (one 34945EXT is automatically
included in each 34945A order)
34946A
Dual 1x2 SPDT terminated microwave
switch
Option 001: No switches installed
Option 004: 4 GHz switches installed
Option 020: 20 GHz switches installed
Option 026: 26.5 GHz switches installed
6 SMA
Requires standard 50 ohm SMA cables and adapters
8710-2576 SMA Extender for connecting SMA
connectors.
Option 001 supports qty 2 of any of the following
switches:
N1810UL unterminated SPDT
N1810TL terminated SPDT
N1811TL terminated 4 port transfer
N1812UL unterminated 5 port transfer
34947A
9 SMA
Requires standard 50 ohm SMA cables and adapters
8710-2576 SMA Extender for connecting SMA
connectors. Option 001 supports qty 3 N1810UL
