Operating Instructions Model No. KXF-4X4C Thank you for purchasing CM301, the modular multi-functional placement machine. Before placing the machine in service, be sure to read the instruction manual for proper usage. Af…
Operating Instructions
Model No.
KXF-4X4C
Thank you for purchasing CM301, the modular multi-functional placement machine.
Before placing the machine in service, be sure to read the instruction manual for
proper usage.
After that, store it carefully and it if necessary.
4X4C-E-IMAB-0003
Modular Multi-functional Placement Machine CM301
Installation Manual
Page 1
“Use of this machine:
This machine is designed and constructed to be used for placing
electric and electronic components on PCB.
This machine shall be used for this purpose only.
It shall not be used for any other purpose.”
“Operation of this machine:
This machine shall be operated by professional, specially trained operators.
It shall not be operated by non-professional, not specially trained operators.
For the training coursed you, make contact with Panasonic Factory Solutions Co., Ltd., PFAE or PIEL.”
Machine was manufactured by: Panasonic Factory Solutions Co., Ltd.
441-13, Nagahasu, Tateishi-machi, Tosu-city, Saga, Japan
TEL:81-942-84-2644
FAX:81-942-84-2636
For Service and Supply of Spares in Europe
you may contact Panasonic Europe:
Continental Europe
PFAE
Panasonic Factory Automation Europe
Winsbergring 15
22525 Hamburg Germany
Phone number :0049-(0)40-85386-321
Fax number : 0049-(0)40-85386-332
United Kingdom
PIEL
Panasonic Industrial Europe (U.K.)
Panasonic House, Willoughby Road
Bracknell, Berks. RG12 8 FP
Phone number : 0044-(0)1344-853267
Fax number : 0044-(0)1344-425970
Year: 2004
4X4C-E-IMA00-B01-01
M11E
DO NOT ALLOW ANY PERSON WHO HAS NOT RECEIVED SPECIAL TRAINING
TO OPERATE THE MACHINE.
The machine may be operated improperly and injure you.
Either carry out training by yourself, or consult the manufacturer.
WARNING
