Chapter 1
INSTALLATION
For the installation
This manual is for the installation of this machine.
The installation should be conducted with the procedure of this manual. Disjointing
the machine for the displacement of the line should be conducted by the procedure
of 1-2 in reverse order.
1-1 Preparations for Installation
This section describes the conditions and how to install the equipment.
1-2 Installing Procedure
This section describes the operating procedures from the installment to
the power supply.
1-3 Assembling Procedure of Surrounding Devices
This section describes how to connect the main surrounding devices.
4X4C-AA00
Page 1-2
4X4C-E-IMA01-A01-00
1-1 Preparations for Installation
1-1-1 Selecting the Location
1. The machine should be placed on the horizontal place.
2. The conditions are as follows. (No moisture condensation).
• Temperature : 10 ˚C to 35 ˚C
• Temperature difference : Lower than 1 ˚C per min
• Humidity : 25 % to 60 %
3. The following condition is also required.
Refer to the arrangement diagram and keep the enough space for maintenance.
