SERIAL PLATE
The serial plate attached to this machine indicates the model name and production number.
DT40T-40U
Actual numbers are shown on the plate instead of ∗.
4X4C-AB00
4M4C-AD00
DT40T-40U
KXF-4Y4C
4X4C-E-IMA00-A03-05
CM301-DU
Actual numbers are shown on the plate instead of ∗.
This is attached on the left end at the rear side of the machine.
This is attached on the left end at the rear side of the machine.
CM301-DU
KXF-4X4C
Page 22
= MEMO =
4X4C-E-IMA00-A03-01
Page 1-1
4X4C-E-IMA01-A01-00
Chapter 1
INSTALLATION
For the installation
This manual is for the installation of this machine.
The installation should be conducted with the procedure of this manual. Disjointing
the machine for the displacement of the line should be conducted by the procedure
of 1-2 in reverse order.
1-1 Preparations for Installation
This section describes the conditions and how to install the equipment.
1-2 Installing Procedure
This section describes the operating procedures from the installment to
the power supply.
1-3 Assembling Procedure of Surrounding Devices
This section describes how to connect the main surrounding devices.
4X4C-AA00
