Page 15 SAFETY PRECAUTIONS Be sure to observe CM301-DU (W arning Labels) The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has come off, put a new one on a proper …
Page 14
SAFETY PRECAUTIONS
Be sure to observe
CM301-DU (Danger Labels)
The following danger labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
M32E
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
4X4C-E-IMA00-A03-00
The positions of danger labels on the front side
4X4C-AA00
The positions of danger labels on the rear side
4X4C-AB00
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
Page 15
SAFETY PRECAUTIONS
Be sure to observe
CM301-DU (Warning Labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
4X4C-E-IMA00-A03-00
The positions of warning labels on the front side
4X4C-AA00
The positions of warning labels on the rear side
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
0 1 N M B
WARNING
WORKER
OPERATING
IN THE BACK
Make sure that no
worker is in the back
when machine
starting.
4X4C-AB00
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
0 1 N L B
WARNING
WORKER
OPERATING
IN THE FRONT
Make sure that no
worker is in the front
when machine
starting.
OPij‘
OPij‘
OPij‘
OPij‘
A
0 1 N C B
WARNING
ELECTRIC
SHOCK
You will have serious
electric shock if you
touch electric active
part inside.
Figure seen from A
Page 16
SAFETY PRECAUTIONS
Be sure to observe
When the Cutting Unit (Option) is Installed
The cutting unit can be installed on this machine as an option.
If installed, the following warning labels are pasted on the machine. Follow the instructions on each label.
If a label has come off, put a new one on a proper position. To order a label from the manufacturer, refer to
PARTS LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
4X4C-E-IMA00-A03-01
The positions of warning labels
Cutting unit
Cutting unit cover
4X4C-AA00
View seen from A
4H4C-022E
View seen from B
A
0 A 5 F B
WARNING
TAKE CARE NOT
TO TOUCH CUTTER
You will have serious
injury if you touch
cutter.
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
4H4C-025E
B
Operation side
4H4C-026E
