Page 17 SAFETY PRECAUTIONS Be sure to observe Direct T win T ray Feeder DT40T -40U (W arning Labels) The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has come off…
Page 16
SAFETY PRECAUTIONS
Be sure to observe
When the Cutting Unit (Option) is Installed
The cutting unit can be installed on this machine as an option.
If installed, the following warning labels are pasted on the machine. Follow the instructions on each label.
If a label has come off, put a new one on a proper position. To order a label from the manufacturer, refer to
PARTS LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
4X4C-E-IMA00-A03-01
The positions of warning labels
Cutting unit
Cutting unit cover
4X4C-AA00
View seen from A
4H4C-022E
View seen from B
A
0 A 5 F B
WARNING
TAKE CARE NOT
TO TOUCH CUTTER
You will have serious
injury if you touch
cutter.
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
4H4C-025E
B
Operation side
4H4C-026E
Page 17
SAFETY PRECAUTIONS
Be sure to observe
Direct Twin Tray Feeder DT40T-40U (Warning Labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
4X4C-E-IMA00-A03-01
The positions of warning labels on the front side
4M4C-AA00
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
The positions of warning labels on the rear side
4M4C-AD00
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
4X4C-E-IMA00-A03-01
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
Page 18
SAFETY PRECAUTIONS
Be sure to observe
4X4C-E-IMA00-A03-01
The positions of warning labels on the rear side
4M4C-AD00
0 1 J K A
Direct Twin Tray Feeder DT40T-40U (Warning Labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
0 1 N 8 A
WARNING
WATCH YOUR
HANDS OR
FINGERS
You will have serious
injury if you touch
active part.
4M4C-AA00
0 1 J K A
The positions of warning labels on the front side
