Station Software 710.1 (R17-1) / Version Description 06/2017 Edition
15
5.2 Camera Systems and Component Ranges
Detailed information on the used camera systems and component ranges for the placement heads
can be found in the respective machine specifications and/or User Manuals of the placement
machines.
Station Software 710.1 (R17-1) / Version Description 06/2017 Edition
16
6 ASM Software Environment
6.1 SIPLACE Pro Programming System Version 14.1
The SIPLACE Pro programming system version 14.1 supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines with the 710.1 station
software version.
Compatible mode: SIPLACE Pro 13.x
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
6.2 ASM OIS Version 14.1
Software version 14.1 of the monitoring system ASM OIS supports the SIPLACE X-series,
X-series S, SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE OIS 13.x
NOTICE
A detailed description can be found in the software
description "Getting started with OIS"
and the online help system for OIS.
6.3 ASM Setup Center Version 9.1
Software version 9.1 of the ASM Setup Center supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Setup Center 8.x
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for Setup Center.
Station Software 710.1 (R17-1) / Version Description 06/2017 Edition
17
6.4 ASM Traceability Version 5.3
Software version 5.3 of ASM Traceability supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Traceability 4.x
NOTICE
A detailed description can be found in the "Traceability User Guide".
