Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

6.4 ASM Traceability Version 5.3

Software version 5.3 of ASM Traceability supports the SIPLACE X-series, X-series S,

SX-series, DX-series, CA-series and TX-series placement machines.

Compatible mode: SIPLACE Traceability 4.x

NOTICE

A detailed description can be found in the "Traceability User Guide".

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

7 Restrictions

For details concerning possible machine configurations, please consult the latest version of the

machine specification.

Restrictions to features in previous versions can be found in the Station Software V7xx Feature

Description, item no. [00197741-xx].

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

8 Corrected Errors

710.1 Station Software

The 710.1 station software version contains all error corrections of the previous 701.x – 710.x

versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-129558314 On WPC6, the components lie below the top edge of the tray.

D1-132588701 Level cannot be refilled on WPC6; level is already on feed axis.

D1-133168801 During production with the Twin VHF head, the CPP head moved to the

placement area and swept away big components from the board.

D1-134664001 The support pins were not put back on the lifting table after having been

returned to the magazine.

D1-134727901 GUI message was incorrect for the Pin Picker endurance run.

D1-135587801 Pin 1 detection for symmetrical components was not possible.

D1-136197701 Software hung up after a USB stick was inserted in the computer.

Table 8-1: Corrected errors station software version 710.1

710.0 Patch 4

Fehlernummer Fehlerbeschreibung

D1-135456343 The yellow signal lamp got active after a track error but was not switched off

after having fixed the problem.

D1-135712643 After having opened and closed the safety circuit the machine dids not make a

reference run but displayed

Waiting for board

D1-136308201

Head verification: CPP verification reported an error.

D1-136508382

D1-136522830

eSW: TX2i with CPP/CP20P: The CPP head was not recognized automatically

after the first machine start.

D1-136529501 The station sent filling level events too often (every 5 seconds).

D1-136683901

eSW: the LBO mode did not work along with an SX4 machine.

D1-136983401 eSW: LBO with backward stopper sporadically did not work in PA1 on an SX4

machine.

D1-137831501 eSW: Borad moved into second station and stayed in input conveyor without

any error message.

D1-137977901 The machine stopped; start and stop buttons were not active and even a

hardware stop/start did not help.

D1-138067701 The machine stopped when an orientation check was carried out.
