Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

D1-138086439 After a setup change all pickup up positions were deactivated at the station.

D1-138513601

From version 709.1 on, barcode fiducials defined in sub-panels were ignored.

D1-138541501 The y axis MFU on gantry 2 / conveyor 1 had a curved result.

D1-138840001

D1-138564301

D1-138862989

D1-139192319

The operating hours were not counted correctly and in some cases reset to 0.

D1-138894801 eSW: Vacuum-tooling on TX widened track displayed an error during

clamping.

D1-138905901 There was an unhandled Windows exception during the Coplan MFU.

D1-138937301 Placement offset of a heavy component because the gantry moved with full

speed during gantry repression.

D1-138953601 Error messages 30506 Hardware warning dp axis and 30576

Unspecified hardware error 0xC

D1-138957949 eSW: Problems with width adjustment when the width was not changed for a

while.

D1-139000201

It was not possible to reject the nozzles when all magazines were occupied.

D1-139002101 The station software stopped during/after placement with the error message

30016 Unhandled exception error

D1-139126101 Although the tray was verified, the operator needed to push the correct

positions button to get the production started.

D1-139191953 Sporadically, the station software stopped during placement with the error

messages 30016 Unhandled exception error and 32602 The

software has stopped unexpectedly

D17667-16852 The machine stopped with the error message 36203 Machine is out of

memory

D17928-19601

D1-139010501

D1-139243601

F1-138458244

The software hung up when activating the image capture during pickup

correction.

D18199-6302 Testing a shield with local fiducial led to the error message 33325 Field of

view of camera is too small for measurement

D18199-7016 When a shield with local fiducial was tested, the searching range was limited.

D18218-9101 No error information was displayed on the GUI.

Table 8-2: Corrected errors station software version 710.0 Patch 4

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

710.0 Patch 3

D1-135754107 Self-test of the station SW: the conveyor motor verification failed as the limits

were too high.

D1-137565101 The Twin head used only one segment although SIPLACE Pro scheduled the

job for both segments.

D1-137636212 The mapping data were not interpolated correctly.

D1-137641858 When checking the LED centering the z axis touched the glass plate and the

software hung up.

D1-137703301 eSW: Cogging force measurement failed due to oscillating gantries.

D1-137762253 There was an unknown hardware error at gantry 4 of the y axis.

D1-137781601 eSW: the conveyor width of conveyor 2 was not restricted although vacuum

tooling was used.

D1-138058601 The gantry offsets should be corrected automatically after having inspected

the chuck fiducials.

Table 8-3: Corrected errors station software version 710.0 Patch 3

710.0 Patch 2

Error no. Error description

D1-131965901 Wrong sequence after a "slope error".

D1-131982201 The "show current board only" function did not work properly.

D1-134286551 The progress bar for the board was missing on the GUI.

D1-134716501 Restarting a failed operation added the error to the error chain once again.

D1-135255401 Sporadically, there were communication problems between the station and

BoardGateKeeper when the barcode was read in the input section.

D1-135304701 Production could not be stopped; a restart of the software was required.

D1-135562301 The amount of discarded components or vision errors was ok at the station but

not in SetupCenter.

D1-135634601 The machine stood still after having taught components during production.

D1-135912817 The machine stopped without a reasonable error message.

D1-135955201 Sporadically, the software hung up when there were setups with a manual

tray.

D1-136159132 eSW: Timing problems along with C&P20 P head control.

D1-136244601 The feeder was still verified although there was a foil torn error.

D1-136286403

D1-137048101

D1-137327501

Location -> I/O settings: error message that there was an IPC communication

error.

D1-136302601 The machine stopped during endurance run with error message command

not implemented

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

D1-136325301 Error message 30016 Unhandled exception error after dp problem.

D1-136451420 With a LED camera an offset correction after ACT was not possible.

D1-136527301 The position of the y axis was out of the travel range.

D1-136558959

D1-136480611

D1-136558901

D1-136619501

The white light started to flash without any error.

D1-136584401 Although the error message segment down; do not move gantry was

displayed, the machine was going on with calibration and moved the gantry.

Reason: the error message was not reset.

D1-136649101 Big components were not displayed completely when they were tested.

D1-136667749 The nozzles were set up and a height reference run was started. Then the

software hung up in status

Checking nozzle configuration

D1-136703901 The Twin Head lost the nozzle when auto recovery was started.

D1-136707101 Although everything seemed to be fine, production of a board did not start.

D1-136708601 The software hung up when the pickup position was taught and had to be

rebooted.

Beim Teachen der Abholposition hing die GUI und die Maschine musste neu

gestartet werden.

D1-136720801 After the eSW download onto the WPC, the message The application

has to be closed

was displayed.

D1-136723403 The GUI closed when the error statistics were reset.

D1-136742701 The station software stopped during/after placement with error message

30016 Unhandled exception error

D1-136807601

D1-136828501

D1-137402984

D1-137403501

The endurance run stopped with too many repetitive errors.

D1-136860282 Head Verification: wrong z axis travel range values for Twin Head and VHF

placement heads.

D1-136872727 Head Verification: There was no summary when the verification was

completed.

D1-136872950 Head Verification: The test bench inspection function for Twin Head or

VHF placement heads displayed 4 buttons but only 2 were usable.

D1-136901201 Head Verification: The nozzle touched the component reject box when the

head was mounted in low position.

D1-136946001 The pickup position recognition worked only for small feeders on special

tracks.

D1-137345201 The machine did not stop after glass plate errors.

D1-137484901 After a SST47 camera error the head rejected all components behind the

camera.

Table 8-4: Corrected errors station software version 710.0 Patch 2
