Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

710.0 Patch 3

D1-135754107 Self-test of the station SW: the conveyor motor verification failed as the limits

were too high.

D1-137565101 The Twin head used only one segment although SIPLACE Pro scheduled the

job for both segments.

D1-137636212 The mapping data were not interpolated correctly.

D1-137641858 When checking the LED centering the z axis touched the glass plate and the

software hung up.

D1-137703301 eSW: Cogging force measurement failed due to oscillating gantries.

D1-137762253 There was an unknown hardware error at gantry 4 of the y axis.

D1-137781601 eSW: the conveyor width of conveyor 2 was not restricted although vacuum

tooling was used.

D1-138058601 The gantry offsets should be corrected automatically after having inspected

the chuck fiducials.

Table 8-3: Corrected errors station software version 710.0 Patch 3

710.0 Patch 2

Error no. Error description

D1-131965901 Wrong sequence after a "slope error".

D1-131982201 The "show current board only" function did not work properly.

D1-134286551 The progress bar for the board was missing on the GUI.

D1-134716501 Restarting a failed operation added the error to the error chain once again.

D1-135255401 Sporadically, there were communication problems between the station and

BoardGateKeeper when the barcode was read in the input section.

D1-135304701 Production could not be stopped; a restart of the software was required.

D1-135562301 The amount of discarded components or vision errors was ok at the station but

not in SetupCenter.

D1-135634601 The machine stood still after having taught components during production.

D1-135912817 The machine stopped without a reasonable error message.

D1-135955201 Sporadically, the software hung up when there were setups with a manual

tray.

D1-136159132 eSW: Timing problems along with C&P20 P head control.

D1-136244601 The feeder was still verified although there was a foil torn error.

D1-136286403

D1-137048101

D1-137327501

Location -> I/O settings: error message that there was an IPC communication

error.

D1-136302601 The machine stopped during endurance run with error message command

not implemented

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

D1-136325301 Error message 30016 Unhandled exception error after dp problem.

D1-136451420 With a LED camera an offset correction after ACT was not possible.

D1-136527301 The position of the y axis was out of the travel range.

D1-136558959

D1-136480611

D1-136558901

D1-136619501

The white light started to flash without any error.

D1-136584401 Although the error message segment down; do not move gantry was

displayed, the machine was going on with calibration and moved the gantry.

Reason: the error message was not reset.

D1-136649101 Big components were not displayed completely when they were tested.

D1-136667749 The nozzles were set up and a height reference run was started. Then the

software hung up in status

Checking nozzle configuration

D1-136703901 The Twin Head lost the nozzle when auto recovery was started.

D1-136707101 Although everything seemed to be fine, production of a board did not start.

D1-136708601 The software hung up when the pickup position was taught and had to be

rebooted.

Beim Teachen der Abholposition hing die GUI und die Maschine musste neu

gestartet werden.

D1-136720801 After the eSW download onto the WPC, the message The application

has to be closed

was displayed.

D1-136723403 The GUI closed when the error statistics were reset.

D1-136742701 The station software stopped during/after placement with error message

30016 Unhandled exception error

D1-136807601

D1-136828501

D1-137402984

D1-137403501

The endurance run stopped with too many repetitive errors.

D1-136860282 Head Verification: wrong z axis travel range values for Twin Head and VHF

placement heads.

D1-136872727 Head Verification: There was no summary when the verification was

completed.

D1-136872950 Head Verification: The test bench inspection function for Twin Head or

VHF placement heads displayed 4 buttons but only 2 were usable.

D1-136901201 Head Verification: The nozzle touched the component reject box when the

head was mounted in low position.

D1-136946001 The pickup position recognition worked only for small feeders on special

tracks.

D1-137345201 The machine did not stop after glass plate errors.

D1-137484901 After a SST47 camera error the head rejected all components behind the

camera.

Table 8-4: Corrected errors station software version 710.0 Patch 2

Station Software 710.1 (R17-1) / Version Description 06/2017 Edition

710.0 Patch 1

Error no. Error description

D1-127726801 There was a message for all four heads that the vacuum was not sufficient.

D1-129449544 eSW: the board was aborted when moving into PA2 but no errors were

displayed.

D1-135009301

D1-135456301

D1-135752301

The station stopped with a track error at the IPTE stick feeder but no error

message was displayed.

D1-135572407 Teaching did not work and a z-axis position error occurred.

D1-135681243 The overall endurance reference run could not be started.

D1-135712601 eSW: Opening and closing the cover lead to error message 30406 Power

output stage deactivated as a result of a faulty PWM

control signal

and the X-/Y-axes had to be referenced again.

D1-135745001 The reference run of the main axes failed.

D1-135752101 The WPC machine data could not be saved.

D1-135795401 After having corrected the pickup position, the station software did not respond

anymore.

D1-135841801 Calibrating the lifting table was not possible in Dual as single mode.

D1-135912801 There was a scale error when LED centering camera SST47 was used.

D1-135985601 A component on the glass plate was reported although there was none.

D17880-44541 All nozzles were thrown away after calibration.

D18082-6001 The machine stopped during production without any error.

D18093-11301 Changed placement offset after fiducials were whispered and the

measurement process was interrupted and then re-started.

D18263-1301 The cycle time was too long because the WPC and Twin Head were waiting

for the new board.

Table 8-5: Corrected errors station software version 710.0 Patch 1
